1AYA

CRYSTAL STRUCTURES OF PEPTIDE COMPLEXES OF THE AMINO-TERMINAL SH2 DOMAIN OF THE SYP TYROSINE PHOSPHATASE

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.05 Å
  • R-Value Work: 0.180
  • R-Value Observed: 0.180

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history.


Literature

Crystal structures of peptide complexes of the amino-terminal SH2 domain of the Syp tyrosine phosphatase.

Lee, C.H., Kominos, D., Jacques, S., Margolis, B., Schlessinger, J., Shoelson, S.E., Kuriyan, J.

(1994) Structure 2: 423-438

  • DOI: https://doi.org/10.1016/s0969-2126(00)00044-7
  • Primary Citation of Related Structures:
    1AYA, 1AYB, 1AYC, 1AYD

  • PubMed Abstract:

    • Src homology 2 (SH2) domains bind to phosphotyrosine residues in a sequence-specific manner, and thereby couple tyrosine phosphorylation to changes in the localization or catalytic activity of signal transducing molecules. Current understanding of SH2 specificity is based on the structures of SH2-peptide complexes of the closely-related Src and Lck tyrosine kinases ...

    Src homology 2 (SH2) domains bind to phosphotyrosine residues in a sequence-specific manner, and thereby couple tyrosine phosphorylation to changes in the localization or catalytic activity of signal transducing molecules. Current understanding of SH2 specificity is based on the structures of SH2-peptide complexes of the closely-related Src and Lck tyrosine kinases. The tyrosine phosphatase Syp contains two SH2 domains that are relatively divergent from those of the tyrosine kinases, with distinct target specificities, and is thus well suited for structural studies aimed at extending our understanding of SH2 specificity.

    Related Citations:
    • Binding of a High Affinity Phosphotyrosyl Peptide to the Src Sh2 Domain: Crystal Structures of the Complexed and Peptide-Free Forms
      Waksman, G., Shoelson, S.E., Pant, N., Cowburn, D., Kuriyan, J.
      (1993) Cell 72: 779
    • Structures of Sh2 and SH3 Domains
      Kuriyan, J., Cowburn, D.
      (1993) Curr Opin Struct Biol 3: 828
    • Crystal Structure of the Phosphotyrosine Recognition Domain Sh2 of V-Src Complexed with Tyrosine-Phosphorylated Peptides
      Waksman, G., Kominos, D., Robertson, S.R., Pant, N., Baltimore, D., Birge, R.B., Cowburn, D., Hanafusa, H., Mayer, B.J., Overduin, M., Resh, M.D., Rios, C.B., Silverman, L., Kuriyan, J.
      (1992) Nature 358: 646
    Organizational Affiliation:

    Laboratory of Molecular Biophysics, Rockefeller University, New York, NY 10021.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
PROTEIN-TYROSINE PHOSPHATASE SYP (N-TERMINAL SH2 DOMAIN)A,
C [auth B]		101Mus musculusMutation(s): 0
Gene Names: Ptpn11
EC: 3.1.3.48
UniProt
Find proteins for P35235 (Mus musculus)
Explore P35235
Go to UniProtKB:  P35235
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP35235
Protein Feature View
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
PEPTIDE PDGFR-1009B [auth P],
D [auth Q]		11Mus musculusMutation(s): 0
Gene Names: Pdgfrb, Pdgfr, Pdgfr1
EC: 2.7.10.1
UniProt & NIH Common Fund Data Resources
Find proteins for P05622 (Mus musculus)
Explore P05622
Go to UniProtKB:  P05622
IMPC:  MGI:97531
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP05622
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
PTR
Query on PTR		B [auth P],
D [auth Q]		L-PEPTIDE LINKINGC9 H12 N O6 PTYR
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.05 Å
  • R-Value Work: 0.180
  • R-Value Observed: 0.180
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 33.8α = 90
b = 52.7β = 101.1
c = 56.4γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
X-PLORphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1994-08-31
    Type: Initial release
  • Version 1.1: 2008-03-03
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
