7ETJ

C5 portal vertex in the partially-enveloped virion capsid

  • Classification: VIRAL PROTEIN
  • Organism(s): Human betaherpesvirus 5
  • Mutation(s): No

  • Deposited: 2021-05-13 Released: 2021-07-14
  • Deposition Author(s): Li, Z., Yu, X.
  • Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural basis for genome packaging, retention, and ejection in human cytomegalovirus.

Li, Z.Pang, J.Dong, L.Yu, X.

(2021) Nat Commun 12: 4538-4538

  • DOI: https://doi.org/10.1038/s41467-021-24820-3
  • Primary Citation of Related Structures:
    7ET2, 7ET3, 7ETJ, 7ETM, 7ETO

  • PubMed Abstract:

    How the human cytomegalovirus (HCMV) genome-the largest among human herpesviruses-is packaged, retained, and ejected remains unclear. We present the in situ structures of the symmetry-mismatched portal and the capsid vertex-specific components (CVSCs) of HCMV. The 5-fold symmetric 10-helix anchor-uncommon among known portals-contacts the portal-encircling DNA, which is presumed to squeeze the portal as the genome packaging proceeds. We surmise that the 10-helix anchor dampens this action to delay the portal reaching a "head-full" packaging state, thus facilitating the large genome to be packaged. The 6-fold symmetric turret, latched via a coiled coil to a helix from a major capsid protein, supports the portal to retain the packaged genome. CVSCs at the penton vertices-presumed to increase inner capsid pressure-display a low stoichiometry, which would aid genome retention. We also demonstrate that the portal and capsid undergo conformational changes to facilitate genome ejection after viral cell entry.


  • Organizational Affiliation

    Cryo-Electron Microscopy Research Center, the CAS Key Laboratory of Receptor Research, Shanghai Institute of Materia Medica, Chinese Academy of Sciences, Shanghai, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Triplex capsid protein 2A [auth h],
B [auth I],
E [auth n],
F [auth o]
306Human betaherpesvirus 5Mutation(s): 0
UniProt
Find proteins for Q6RXF2 (Human cytomegalovirus)
Explore Q6RXF2
Go to UniProtKB:  Q6RXF2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6RXF2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Large tegument protein deneddylaseC [auth H],
D [auth P]
2,241Human betaherpesvirus 5Mutation(s): 0
EC: 3.4.19.12 (PDB Primary Data), 3.4.22 (PDB Primary Data)
UniProt
Find proteins for A0A3G6XL22 (Human cytomegalovirus)
Explore A0A3G6XL22
Go to UniProtKB:  A0A3G6XL22
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A3G6XL22
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Triplex capsid protein 1G [auth g],
H [auth m]
290Human betaherpesvirus 5Mutation(s): 0
UniProt
Find proteins for Q6RXH2 (Human cytomegalovirus)
Explore Q6RXH2
Go to UniProtKB:  Q6RXH2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6RXH2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Capsid vertex component 1I [auth M]594Human betaherpesvirus 5Mutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Capsid vertex component 2J [auth N],
K [auth O]
642Human betaherpesvirus 5Mutation(s): 0
UniProt
Find proteins for A0A3G6XKK5 (Human cytomegalovirus)
Explore A0A3G6XKK5
Go to UniProtKB:  A0A3G6XKK5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A3G6XKK5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
ORFL92C_UL32L [auth 1]1,048Human betaherpesvirus 5Mutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Small capsomere-interacting proteinM [auth R],
N [auth S],
O [auth T],
P [auth i],
Q [auth j]
75Human betaherpesvirus 5Mutation(s): 0
UniProt
Find proteins for A8T7C4 (Human cytomegalovirus)
Explore A8T7C4
Go to UniProtKB:  A8T7C4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8T7C4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Major capsid protein1,370Human betaherpesvirus 5Mutation(s): 0
UniProt
Find proteins for A0A1U8QPG3 (Human cytomegalovirus)
Explore A0A1U8QPG3
Go to UniProtKB:  A0A1U8QPG3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1U8QPG3
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.00 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data

  • Released Date: 2021-07-14
  • Deposition Author(s): Li, Z., Yu, X.

Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China31900869

Revision History  (Full details and data files)

  • Version 1.0: 2021-07-14
    Type: Initial release
  • Version 1.1: 2021-08-18
    Changes: Database references
