9FPC | pdb_00009fpc

Architectural insights into the corrin and metal binding sites of CobN cobaltochelatase

PDB DOI: https://doi.org/10.2210/pdb9FPC/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Brucella melitensis
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-06-13 Released: 2025-06-25
Deposition Author(s): Pickersgill, R.W.
Funding Organization(s): Biotechnology and Biological Sciences Research Council (BBSRC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.97 Å
R-Value Free:
0.229 (Depositor), 0.217 (DCC)
R-Value Work:
0.173 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 9FPC

This is version 1.0 of the entry. See complete history.

Literature

Architectural insights into the corrin and metal binding sites of CobN cobaltochelatase

Pickersgill, R.W., Brown, D.G., Ladakis, D., Warren, M.J.

To be published.

Macromolecule Content

Total Structure Weight: 42.06 kDa
Atom Count: 3,168
Modeled Residue Count: 384
Deposited Residue Count: 384
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cobn protein	A	384	Brucella melitensis	Mutation(s): 0 Gene Names: BMEI0695 EC: 6.6.1.2
UniProt
Find proteins for Q8YHV1 (Brucella melitensis biotype 1 (strain ATCC 23456 / CCUG 17765 / NCTC 10094 / 16M)) Explore Q8YHV1 Go to UniProtKB: Q8YHV1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8YHV1
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.97 Å
R-Value Free: 0.229 (Depositor), 0.217 (DCC)
R-Value Work: 0.173 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.13	α = 90
b = 74.19	β = 90
c = 85.89	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
BUCCANEER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-06-25

Deposition Author(s):

Pickersgill, R.W.

Funding Organization	Location	Grant Number
Biotechnology and Biological Sciences Research Council (BBSRC)	United Kingdom	BB/X001946/1

Revision History (Full details and data files)

Version 1.0: 2025-06-25
Type: Initial release
