9EY3 | pdb_00009ey3

The FK1 domain of FKBP51 in complex with (3S,11S,11aS)-12-((3,5-dichlorophenyl)sulfonyl)-5-oxo-11-vinyldecahydro-1H-6,10-epiminopyrrolo[1,2-a]azonine-3-carboxylic acid


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.16 Å
  • R-Value Free:
    0.168 (Depositor), 0.171 (DCC)
  • R-Value Work:
    0.139 (Depositor), 0.150 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9EY3

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Structure-Based Design of Ultrapotent Tricyclic Ligands for FK506-Binding Proteins.

Krajczy, P.Meyners, C.Repity, M.L.Hausch, F.

(2024) Chemistry 30: e202401405-e202401405

  • DOI: https://doi.org/10.1002/chem.202401405
  • Primary Citation Related Structures:
    9EY3, 9EY4

  • PubMed Abstract:

    Access to small, rigid, and sp3-rich molecules is a major limitation in the drug discovery for challenging protein targets. FK506-binding proteins hold high potential as drug targets or enablers of molecular glues but are fastidious in the chemotypes accepted as ligands. We here report an enantioselective synthesis of a highly rigidified pipecolate-mimicking tricyclic scaffold that precisely position functional groups for interacting with FKBPs. This was enabled by a 14-step gram-scale synthesis featuring anodic oxidation, stereospecific vinylation, and N-acyl iminium cyclization. Structure-based optimization resulted in the discovery of FKBP inhibitors with picomolar biochemical and subnanomolar cellular activity that represent the most potent FKBP ligands known to date.


  • Organizational Affiliation
    • Technische Universitat Darmstadt, Chemistry, GERMANY.

Macromolecule Content

  • Total Structure Weight: 14.48 kDa
  • Atom Count: 1,233
  • Modeled Residue Count: 127
  • Deposited Residue Count: 128
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Peptidyl-prolyl cis-trans isomerase FKBP5128Homo sapiensMutation(s): 3
Gene Names: FKBP5AIG6FKBP51
EC: 5.2.1.8
UniProt & NIH Common Fund Data Resources
Find proteins for Q13451 (Homo sapiens)
Explore Q13451
Go to UniProtKB:  Q13451
PHAROS:  Q13451
GTEx:  ENSG00000096060
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13451
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1H70
(Subject of Investigation/LOI)

Query on A1H70



Download:Ideal Coordinates CCD File
B [auth A](1~{S},4~{S},7~{S},8~{S},9~{R})-13-[3,5-bis(chloranyl)phenyl]sulfonyl-8-ethenyl-2-oxidanylidene-3,13-diazatricyclo[7.3.1.0^{3,7}]tridecane-4-carboxylic acid
C20 H22 Cl2 N2 O5 S
SRHNUYKTBCXYAO-JCECYMMASA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.16 Å
  • R-Value Free:  0.168 (Depositor), 0.171 (DCC)
  • R-Value Work:  0.139 (Depositor), 0.150 (DCC)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.077α = 90
b = 54.553β = 90
c = 56.322γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Federal Ministry for Education and ResearchGermany--

Revision History  (Full details and data files)

  • Version 1.0: 2024-06-12
    Type: Initial release
  • Version 1.1: 2024-08-21
    Changes: Database references
  • Version 1.2: 2024-08-28
    Changes: Database references
