9DYT | pdb_00009dyt

Acanthamoeba Polyphaga Mimivirus R699

• PDB DOI: https://doi.org/10.2210/pdb9DYT/pdb

• Classification: VIRAL PROTEIN
• Organism(s): Acanthamoeba polyphaga mimivirus
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2024-10-14 Released: 2025-06-11
• Deposition Author(s): Richards, S.J., Buhlheller, C., Kim, J.S., Chen, T., Wu, J., Guo, H.
• Funding Organization(s): National Institutes of Health/National Cancer Institute (NIH/NCI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:
  0.220 (Depositor), 0.224 (DCC)
• R-Value Work:
  0.190 (Depositor), 0.193 (DCC)

Starting Model: experimental

Literature

Acanthamoeba Polyphaga Mimivirus R699

Richards, S.J., Buhlheller, C., Kim, J.S., Chen, T., Wu, J., Guo, H.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors.

Macromolecule Content

• Total Structure Weight: 106.74 kDa
• Atom Count: 7,789
• Modeled Residue Count: 875
• Deposited Residue Count: 916
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
R699	A, B	458	Acanthamoeba polyphaga mimivirus	Mutation(s): 0  Gene Names: MIMI_R699
UniProt
Find proteins for Q5UNV6 (Acanthamoeba polyphaga mimivirus) Explore Q5UNV6  Go to UniProtKB:  Q5UNV6

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MN (Subject of Investigation/LOI)	C [auth A], D [auth B]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:  0.220 (Depositor), 0.224 (DCC)
• R-Value Work:  0.190 (Depositor), 0.193 (DCC)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 69.821	α = 90
b = 121.696	β = 118.589
c = 72.69	γ = 90

Software Package:

Software Name	Purpose
DIALS	data collection
xia2	data reduction
Aimless	data scaling
PHENIX	phasing
PHASER	phasing
Coot	model building
REFMAC	refinement

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-06-11
Deposition Author(s): Richards, S.J., Buhlheller, C., Kim, J.S., Chen, T., Wu, J., Guo, H.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)	United States	R00CA225633
National Institutes of Health/National Cancer Institute (NIH/NCI)	United States	R37CA278989

Revision History

• Version 1.0: 2025-06-11
  Type: Initial release
