9DLV | pdb_00009dlv

Cryo-EM structure of the human TREX-2.1 complex (LENG8/PCID2/DSS1) bound to DDX39B(UAP56)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.97 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9DLV

This is version 1.1 of the entry. See complete history

Literature

Structural mechanism of DDX39B regulation by human TREX-2 and a related complex in mRNP remodeling.

Clarke, B.P.Gao, S.Mei, M.Xie, D.Angelos, A.E.Vazhavilla, A.Hill, P.S.Cagatay, T.Batten, K.Shay, J.W.Xie, Y.Fontoura, B.M.A.Ren, Y.

(2025) Nat Commun 16: 5471-5471

  • DOI: https://doi.org/10.1038/s41467-025-60547-1
  • Primary Citation Related Structures:
    9DLP, 9DLR, 9DLV

  • PubMed Abstract:

    Nuclear export of mRNAs in the form of messenger ribonucleoprotein particles (mRNPs) is an obligatory step for eukaryotic gene expression. The DEAD-box ATPase DDX39B (also known as UAP56) is a multifunctional regulator of nuclear mRNPs. How DDX39B mediates mRNP assembly and export in a controlled manner remains elusive. Here, we identify a novel complex TREX-2.1 localized in the nucleus that facilitates the release of DDX39B from the mRNP. TREX-2.1 is composed of three subunits, LENG8, PCID2, and DSS1, and shares the latter two subunits with the nuclear pore complex-associated TREX-2 complex. Cryo-EM structures of TREX-2.1/DDX39B and TREX-2/DDX39B identify a conserved trigger loop in the LENG8 and GANP subunit of the respective TREX-2.1 and TREX-2 complex that is critical for DDX39B regulation. RNA sequencing from LENG8 knockdown cells shows that LENG8 influences the nucleocytoplasmic ratio of a subset of mRNAs with high GC content. Together, our findings lead to a mechanistic understanding of the functional cycle of DDX39B and its regulation by TREX-2 and TREX-2.1 in mRNP processing.


  • Organizational Affiliation
    • Department of Biochemistry, Vanderbilt University School of Medicine, Nashville, TN, USA.

Macromolecule Content

  • Total Structure Weight: 139.86 kDa
  • Atom Count: 7,245
  • Modeled Residue Count: 896
  • Deposited Residue Count: 1,218
  • Unique protein chains: 4

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Leukocyte receptor cluster member 8316Homo sapiensMutation(s): 0
Gene Names: LENG8KIAA1932
UniProt & NIH Common Fund Data Resources
Find proteins for Q96PV6 (Homo sapiens)
Explore Q96PV6
Go to UniProtKB:  Q96PV6
PHAROS:  Q96PV6
GTEx:  ENSG00000167615
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ96PV6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
PCI domain-containing protein 2399Homo sapiensMutation(s): 0
Gene Names: PCID2HT004
UniProt & NIH Common Fund Data Resources
Find proteins for Q5JVF3 (Homo sapiens)
Explore Q5JVF3
Go to UniProtKB:  Q5JVF3
PHAROS:  Q5JVF3
GTEx:  ENSG00000126226
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JVF3
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
26S proteasome complex subunit SEM170Homo sapiensMutation(s): 0
Gene Names: SEM1C7orf76DSS1SHFDG1SHFM1
UniProt & NIH Common Fund Data Resources
Find proteins for P60896 (Homo sapiens)
Explore P60896
Go to UniProtKB:  P60896
PHAROS:  P60896
GTEx:  ENSG00000127922
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60896
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Spliceosome RNA helicase DDX39B433Homo sapiensMutation(s): 0
Gene Names: DDX39BBAT1UAP56
EC: 3.6.4.13
UniProt & NIH Common Fund Data Resources
Find proteins for Q13838 (Homo sapiens)
Explore Q13838
Go to UniProtKB:  Q13838
PHAROS:  Q13838
GTEx:  ENSG00000198563
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13838
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.97 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.21.1_5286

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2025-09-17
    Type: Initial release
  • Version 1.1: 2025-11-12
    Changes: Data collection, Database references
