9ZB7 | pdb_00009zb7

A DARPin fused to the 1TEL crystallization chaperone via a direct helical fusion

PDB DOI: https://doi.org/10.2210/pdb9ZB7/pdb

Classification: TRANSCRIPTION
Organism(s): Homo sapiens, synthetic construct
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2025-11-20 Released: 2025-12-17
Deposition Author(s): Averett, J.C., Bradford, M.J., Wilson, E.W., Averett, B.J., Anderson, E., Anderson, A., Doukov, T., Moody, J.D.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.24 Å
R-Value Free:
0.170 (Depositor), 0.170 (DCC)
R-Value Work:
0.146 (Depositor), 0.145 (DCC)
R-Value Observed:
0.147 (Depositor)

Starting Models: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Polymer crystallization physics discovered through modulating the pH sensitivity of the TELSAM crystallization chaperone for increased solubility

Averett, J.C., Bradford, M.J., Wilson, E.W., Yseng, Y.J., Averett, B.J., Anderson, E., Anderson, A., Doukov, T., Moody, J.D.

To be published.

Macromolecule Content

Total Structure Weight: 28.29 kDa
Atom Count: 2,105
Modeled Residue Count: 238
Deposited Residue Count: 243
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transcription factor ETV6,DARPin	A	243	Homo sapiens, synthetic construct This entity is chimeric	Mutation(s): 1 Gene Names: ETV6, TEL, TEL1
UniProt & NIH Common Fund Data Resources
Find proteins for P41212 (Homo sapiens) Explore P41212 Go to UniProtKB: P41212
PHAROS: P41212 GTEx: ENSG00000139083
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P41212
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
AKG Query on AKG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	2-OXOGLUTARIC ACID C₅ H₆ O₅ KPGXRSRHYNQIFN-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain R [auth A] SDF format, chain S [auth A] SDF format, chain T [auth A] SDF format, chain U [auth A] MOL2 format, chain R [auth A] MOL2 format, chain S [auth A] MOL2 format, chain T [auth A] MOL2 format, chain U [auth A] mmCIF format, chain R [auth A] mmCIF format, chain S [auth A] mmCIF format, chain T [auth A] mmCIF format, chain U [auth A]	R [auth A], S [auth A], T [auth A], U [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Interactions & Density Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A]	D [auth A], E [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A]
EOH Query on EOH Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A]	F [auth A], G [auth A]	ETHANOL C₂ H₆ O LFQSCWFLJHTTHZ-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A]
K Query on K Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A]	H [auth A], I [auth A], J [auth A], K [auth A], L [auth A]	POTASSIUM ION K NPYPAHLBTDXSSS-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain Q [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain Q [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A] mmCIF format, chain Q [auth A]	M [auth A], N [auth A], O [auth A], P [auth A], Q [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Interactions & Density Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A]
NH4 Query on NH4 Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	AMMONIUM ION H₄ N QGZKDVFQNNGYKY-UHFFFAOYSA-O		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.24 Å
R-Value Free: 0.170 (Depositor), 0.170 (DCC)
R-Value Work: 0.146 (Depositor), 0.145 (DCC)
R-Value Observed: 0.147 (Depositor)

Space Group: P 6₅

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 83.69	α = 90
b = 83.69	β = 90
c = 58.491	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB-REDO	refinement
XDS	data reduction
autoPROC	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-12-17

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	1R15GM146209
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	1R35GM155011
