9W4U | pdb_00009w4u

ASFV E146L

PDB DOI: https://doi.org/10.2210/pdb9W4U/pdb

Classification: VIRAL PROTEIN
Organism(s): African swine fever virus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-08-01 Released: 2025-09-17
Deposition Author(s): Yong, W., DongDong, D.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.227 (Depositor), 0.225 (DCC)
R-Value Work:
0.184 (Depositor), 0.185 (DCC)
R-Value Observed:
0.186 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

crystal structure of ASFV E146L

Yong, W.

To be published.

Macromolecule Content

Total Structure Weight: 53.43 kDa
Atom Count: 3,966
Modeled Residue Count: 463
Deposited Residue Count: 488
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ASFV E146L	A, B, C, D	122	African swine fever virus	Mutation(s): 0
UniProt
Find proteins for Q65197 (African swine fever virus (strain Badajoz 1971 Vero-adapted)) Explore Q65197 Go to UniProtKB: Q65197
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q65197
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.227 (Depositor), 0.225 (DCC)
R-Value Work: 0.184 (Depositor), 0.185 (DCC)
R-Value Observed: 0.186 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 50.068	α = 77.09
b = 50.137	β = 80.1
c = 50.399	γ = 77.78

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
autoPX	data processing
PHENIX	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-09-17

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2025-09-17
Type: Initial release
