 9UBS | pdb_00009ubs

The structure of the AglA_T220R-Arg complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.49 Å
  • R-Value Free:
    0.191 (Depositor), 0.192 (DCC)
  • R-Value Work:
    0.166 (Depositor), 0.166 (DCC)
  • R-Value Observed:
    0.167 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9UBS

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history.

Literature

A Dynamic Gate Enables Regioselective Hydroxylation of Free Arginine by a Non-Canonical Heme Enzyme.

Sun, Y., Dou, C., Yan, W., Chen, P., Zhang, L., Zhou, D., Zheng, Y., Long, Z., Li, S., Xu, X., Huang, Q., Zhu, X., Cheng, W.

(2026) Adv Sci (Weinh) 13: e13032-e13032

  • DOI: https://doi.org/10.1002/advs.202513032
  • Primary Citation Related Structures:
    9UB3, 9UB5, 9UBA, 9UBB, 9UBS, 9UBT

  • PubMed Abstract:

    The YqcI/YcgG family of heme-dependent enzymes catalyzes guanidine N-H hydroxylation, a critical yet enigmatic step in bioactive natural product biosynthesis. Here, this mechanistic puzzle is resolved through high-resolution structural snapshots of AglA, a prototypical YqcI/YcgG member, revealing a non-canonical heme-binding "sandwich" fold. A dynamic regiochemical gating mechanism is uncovered: substrate-induced remodeling of loop L2 and key residues (Phe152, Arg179, Phe182) spatially constrains the guanidine group of aminomethylphosphonate-linked arginine (AMPn-Arg), enforcing exclusive internal N ε hydroxylation. Single-site mutations rewire hydrogen-bond networks to enable hydroxylation of free L-arginine with controllable regioselectivity (internal N δ vs terminal N ω ) while preserving native internal N ε selectivity for AMPn-Arg. Crystal structures of engineered variants with free arginine, together with MD simulations, explain how subtle rearrangements of loop L2 and residues Phe152/Arg179/Phe182 pivot the guanidinium group relative to the heme Fe(IV) = O intermediate. Fusing AglA to its native PDR/VanB reductase yields a self-sufficient chimera with improved catalytic efficiency. This work establishes a structural blueprint for tuning guanidino N-H hydroxylation and demonstrates proof-of-principle control of regioselectivity in a non-canonical heme enzyme, thereby advancing the synthesis of arginine-based antibiotics and precision-functionalized therapeutics.


  • Organizational Affiliation:
    • Department of Pulmonary and Critical Care Medicine, Respiratory Infection and Intervention Laboratory of Frontiers Science Center for Disease-related Molecular Network, and State Key Laboratory of Biotherapy, West China Hospital of Sichuan University, Chengdu, 610041, China.

Macromolecule Content

  • Total Structure Weight: 31.63 kDa
  • Atom Count: 2,308
  • Modeled Residue Count: 240
  • Deposited Residue Count: 274
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
YqcI/YcgG family protein AglA274Streptomyces monomyciniMutation(s): 0
UniProt
Find proteins for A0A401WFM4 (Streptomyces paromomycinus)
Explore A0A401WFM4
Go to UniProtKB:  A0A401WFM4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A401WFM4
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.49 Å
  • R-Value Free:  0.191 (Depositor), 0.192 (DCC)
  • R-Value Work:  0.166 (Depositor), 0.166 (DCC)
  • R-Value Observed: 0.167 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 47.974α = 90
b = 72.394β = 90
c = 75.197γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China32225001
National Natural Science Foundation of China (NSFC)China32200114

Revision History  (Full details and data files)

  • Version 1.0: 2025-12-10
    Type: Initial release
  • Version 1.1: 2026-02-18
    Changes: Database references
  • Version 1.2: 2026-07-08
    Changes: Database references
  • Version 1.3: 2026-08-12
    Type: Remediation
    Reason: Metalloprotein remediation
    Changes: Derived calculations, Structure summary
