9SL9 | pdb_00009sl9

Structure of recombinant human butyrylcholinesterase in complex with (2S, 3R)-2-(pyridin-3-ylmethyl)quinuclidin-3-yl phenylcarbamate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.69 Å
  • R-Value Free:
    0.234 (Depositor), 0.233 (DCC)
  • R-Value Work:
    0.176 (Depositor), 0.177 (DCC)
  • R-Value Observed:
    0.179 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Dual cholinergic modulation in dementia: Quinuclidine carbamates targeting butyrylcholinesterase and alpha 7 nicotinic receptor.

Mastnak-Sokolov, P.Knez, D.Meden, A.Strasek Benedik, N.Ferjancic Benetik, S.Hrast Rambaher, M.Zorman, M.Nachon, F.Brazzolotto, X.Jardemark, K.Jungholm, O.Bruton, J.Strandback, E.Nyman, T.Shahid, M.Gobec, S.

(2025) Chem Biol Interact 423: 111830-111830

  • DOI: https://doi.org/10.1016/j.cbi.2025.111830
  • Primary Citation of Related Structures:
    9SL8, 9SL9

  • PubMed Abstract:

    Alzheimer's disease (AD) is the leading cause of dementia worldwide, but current therapies provide only symptomatic relief. Multi-target directed ligands (MTDLs) represent a promising approach to address AD pathology by modulating multiple targets with a single molecule. Here we describe quinuclidine carbamates that act simultaneously on butyrylcholinesterase (BChE) and the cholinergic α7 nicotinic receptor (α7 nAChR), thereby approaching cholinergic dysfunction at two levels: by modulating acetylcholine degradation and by direct agonism at this receptor. Starting with the α7 nAChR agonist bradanicline, its amide group was replaced by a carbamate moiety to enhance BChE inhibition while retaining receptor agonism. These quinuclidine carbamates inhibited BChE in the submicromolar range with the desired selectivity over acetylcholinesterase (AChE). In a calcium-flux assay on recombinant HEK293T cells expressing the α7 nAChR, all compounds were agonists of the α7 nAChR in the nanomolar range. Importantly, compound 6b displayed balanced, submicromolar activity against both targets. The crystal structures confirmed non-covalent binding to the active site of human BChE, and the 6b-hBChE complex also revealed an unprecedented flip of Tyr440, representing the first described example of backdoor opening for hBChE. Taken together, these results demonstrate that quinuclidine carbamates are promising dual modulators of hBChE and α7 nAChR, supporting their potential as MTDLs for AD therapy and highlighting this underexplored dual-target strategy as a promising approach in cholinergic drug discovery.


  • Organizational Affiliation
    • Faculty of Pharmacy, University of Ljubljana, Aškerčeva cesta 7, 1000, Ljubljana, Slovenia.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cholinesterase529Homo sapiensMutation(s): 4
Gene Names: BCHECHE1
EC: 3.1.1.8
UniProt & NIH Common Fund Data Resources
Find proteins for P06276 (Homo sapiens)
Explore P06276
Go to UniProtKB:  P06276
PHAROS:  P06276
GTEx:  ENSG00000114200
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP06276
Glycosylation
Glycosylation Sites: 6Go to GlyGen: P06276-1
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
alpha-L-fucopyranose-(1-6)-2-acetamido-2-deoxy-beta-D-glucopyranose
B
2N-Glycosylation
Glycosylation Resources
GlyTouCan:  G86851RC
GlyCosmos:  G86851RC
GlyGen:  G86851RC
Entity ID: 3
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose
C, D
3N-Glycosylation
Glycosylation Resources
GlyTouCan:  G21290RB
GlyCosmos:  G21290RB
GlyGen:  G21290RB
Entity ID: 4
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
E
2N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1JOI (Subject of Investigation/LOI)
Query on A1JOI

Download Ideal Coordinates CCD File
H [auth A][(2~{S},3~{R})-2-(pyridin-3-ylmethyl)-1-azabicyclo[2.2.2]octan-3-yl] ~{N}-phenylcarbamate
C20 H23 N3 O2
PMTJTOSHJSYWNV-RBUKOAKNSA-N
NAG
Query on NAG

Download Ideal Coordinates CCD File
F [auth A],
G [auth A]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
I [auth A],
J [auth A],
K [auth A],
L [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
CL
Query on CL

Download Ideal Coordinates CCD File
M [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA
Query on NA

Download Ideal Coordinates CCD File
N [auth A]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.69 Å
  • R-Value Free:  0.234 (Depositor), 0.233 (DCC)
  • R-Value Work:  0.176 (Depositor), 0.177 (DCC)
  • R-Value Observed: 0.179 (Depositor)
Space Group: I 4 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 154.466α = 90
b = 154.466β = 90
c = 127.91γ = 90
Software Package:
Software NamePurpose
MxCuBEdata collection
XDSdata reduction
XSCALEdata scaling
PHASERphasing
Cootmodel building
PHENIXrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
French Ministry of Armed ForcesFranceNBC-5-C-2316

Revision History  (Full details and data files)

  • Version 1.0: 2025-11-26
    Type: Initial release
