9QZ0 | pdb_00009qz0

MINPP1 from Bacteroides thetaiotaomicron E325N mutant complex with myo-inositol hexakisphosphate

PDB DOI: https://doi.org/10.2210/pdb9QZ0/pdb

Classification: HYDROLASE
Organism(s): Bacteroides thetaiotaomicron VPI-5482
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2025-04-22 Released: 2025-05-14
Deposition Author(s): Li, A.W.H., Shang, X.Y., Hemmings, A.M.
Funding Organization(s): Biotechnology and Biological Sciences Research Council (BBSRC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.86 Å
R-Value Free:
0.193 (Depositor), 0.193 (DCC)
R-Value Work:
0.165 (Depositor), 0.165 (DCC)
R-Value Observed:
0.167 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9QZ0

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

A Structural Basis for the Stereospecificity of Multiple Inositol Polyphosphate Phosphatases

Salmon, M., Shang, X.Y., Li, A.W.H., Hemmings, A.M.

To be published.

Macromolecule Content

Total Structure Weight: 100.36 kDa
Atom Count: 7,282
Modeled Residue Count: 787
Deposited Residue Count: 852
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
multiple inositol polyphosphate histidine phosphatase 1	A [auth AA], B [auth BA]	426	Bacteroides thetaiotaomicron VPI-5482	Mutation(s): 1 Gene Names: BT_4744 EC: 3.1.3.62 (UniProt), 3.1.3.80 (UniProt)
UniProt
Find proteins for Q89YI8 (Bacteroides thetaiotaomicron (strain ATCC 29148 / DSM 2079 / JCM 5827 / CCUG 10774 / NCTC 10582 / VPI-5482 / E50)) Explore Q89YI8 Go to UniProtKB: Q89YI8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q89YI8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
IHP (Subject of Investigation/LOI) Query on IHP Download:Ideal Coordinates CCD File SDF format, chain E [auth BA] SDF format, chain D [auth AA] SDF format, chain C [auth AA] MOL2 format, chain E [auth BA] MOL2 format, chain D [auth AA] MOL2 format, chain C [auth AA] mmCIF format, chain E [auth BA] mmCIF format, chain D [auth AA] mmCIF format, chain C [auth AA]	C [auth AA], D [auth AA], E [auth BA]	INOSITOL HEXAKISPHOSPHATE C₆ H₁₈ O₂₄ P₆ IMQLKJBTEOYOSI-GPIVLXJGSA-N		Interactions Focus chain C [auth AA] Focus chain D [auth AA] Focus chain E [auth BA] Interactions & Density Focus chain C [auth AA] Focus chain D [auth AA] Focus chain E [auth BA]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.86 Å
R-Value Free: 0.193 (Depositor), 0.193 (DCC)
R-Value Work: 0.165 (Depositor), 0.165 (DCC)
R-Value Observed: 0.167 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 52.833	α = 90
b = 120.41	β = 108.04
c = 75.939	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
xia2	data reduction
xia2	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-05-14

Deposition Author(s):

Funding Organization	Location	Grant Number
Biotechnology and Biological Sciences Research Council (BBSRC)	United Kingdom	BB/M022978/1

Revision History (Full details and data files)

Version 1.0: 2025-05-14
Type: Initial release
