9PE8 | pdb_00009pe8

CDK6 to CDK4 active site surrogate in complex with PF-07220060


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:
    0.252 (Depositor), 0.245 (DCC)
  • R-Value Work:
    0.224 (Depositor), 0.215 (DCC)
  • R-Value Observed:
    0.226 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9PE8

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Discovery of Atirmociclib (PF-07220060): A Potent and Selective CDK4 Inhibitor.

Gallego, G.M.Palmer, C.Orr, S.Bernier, L.Chen, P.Cho-Schultz, S.Deal, J.G.Dress, K.Edwards, M.Jalaie, M.Johnson, E.Kania, R.Kath, J.C.Lafontaine, J.Ninkovic, S.Sach, N.Shen, H.Anders, L.Boras, B.Cao, F.Cianfrogna, J.A.Cox, L.Marroquin, L.Pascual, B.Petroski, M.Quinlan, C.Sacaan, A.Wei, N.Nair, S.K.

(2025) J Med Chem 68: 26085-26098

  • DOI: https://doi.org/10.1021/acs.jmedchem.5c02137
  • Primary Citation Related Structures:
    9PE7, 9PE8, 9PE9

  • PubMed Abstract:

    Inhibitors of cyclin-dependent kinases 4 and 6 have been shown to be clinically effective for the treatment of hormone receptor-positive (HR+), human epidermal growth factor receptor 2-negative (HER2-) advanced, or metastatic breast cancer. These agents, however, often show neutropenia, likely due to the role of CDK6 in hematopoiesis. Herein described is the discovery of a series of aminopyrimidine-based selective CDK4 inhibitors. Central to our strategy were efficiency-based optimization (LipE and LipMetE), structure-based drug design, and molecular dynamics simulation. The culmination of these efforts resulted in the discovery of PF-07220060 (atirmociclib), which possessed high potency and levels of selectivity for CDK4 over CDK6 that translated to minimal impact on neutrophils while driving efficacy in a mouse ZR75-1 xenograft model.


  • Organizational Affiliation
    • Oncology Medicinal Chemistry, Pfizer Worldwide Research and Development, La Jolla, San Diego, California 92121, United States.

Macromolecule Content

  • Total Structure Weight: 35.48 kDa
  • Atom Count: 2,344
  • Modeled Residue Count: 267
  • Deposited Residue Count: 307
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Cyclin-dependent kinase 6307Homo sapiensMutation(s): 4
Gene Names: CDK6CDKN6
EC: 2.7.11.22
UniProt & NIH Common Fund Data Resources
Find proteins for Q00534 (Homo sapiens)
Explore Q00534
Go to UniProtKB:  Q00534
PHAROS:  Q00534
GTEx:  ENSG00000105810
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ00534
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1AZ4
(Subject of Investigation/LOI)

Query on A1AZ4



Download:Ideal Coordinates CCD File
B [auth A]Atirmociclib
C22 H27 Cl F N5 O3
QYJLBHRAPDJOSO-NVXWUHKLSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:  0.252 (Depositor), 0.245 (DCC)
  • R-Value Work:  0.224 (Depositor), 0.215 (DCC)
  • R-Value Observed: 0.226 (Depositor)
Space Group: I 4
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 101.27α = 90
b = 101.27β = 90
c = 59.45γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
Aimlessdata scaling
autoBUSTERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not fundedUnited States--

Revision History  (Full details and data files)

  • Version 1.0: 2025-12-17
    Type: Initial release
  • Version 1.1: 2025-12-31
    Changes: Database references
