9P99 | pdb_00009p99

CryoEM structure of integrin alphaEbeta7 bound to E-cadherin


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.37 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Molecular exaptation by the integrin alpha I domain.

Hollis, J.A.Chan, M.C.Malik, H.S.Campbell, M.G.

(2025) Sci Adv 11: eadx9567-eadx9567

  • DOI: https://doi.org/10.1126/sciadv.adx9567
  • Primary Citation of Related Structures:
    9P95, 9P96, 9P97, 9P98, 9P99

  • PubMed Abstract:

    Integrins bind ligands between their alpha (α) and beta (β) subunits and transmit signals through conformational changes. Early in chordate evolution, some α subunits acquired an "inserted" (I) domain that expanded integrin's ligand-binding repertoire but obstructed the ancestral ligand pocket, seemingly blocking conventional integrin activation. Here, we compare cryo-electron microscopy structures of apo and ligand-bound states of the I domain-containing αEβ 7 integrin and the I domain-lacking α 4 β 7 integrin to illuminate how the I domain intrinsically mimics an extrinsic ligand to preserve integrin function. We trace the I domain's evolutionary origin to an ancestral collagen-collagen interaction domain, identifying an ancient molecular exaptation that facilitated integrin activation immediately upon I domain insertion. Our analyses reveal the evolutionary and biochemical basis of expanded cellular communication in vertebrates.


  • Organizational Affiliation
    • Division of Basic Sciences, Fred Hutchinson Cancer Center, Seattle, WA 98109, USA.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Integrin alpha-E1,176Homo sapiensMutation(s): 0
Gene Names: ITGAE
UniProt & NIH Common Fund Data Resources
Find proteins for P38570 (Homo sapiens)
Explore P38570
Go to UniProtKB:  P38570
PHAROS:  P38570
GTEx:  ENSG00000083457
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38570
Glycosylation
Glycosylation Sites: 5Go to GlyGen: P38570-1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Integrin beta-7776Homo sapiensMutation(s): 0
Gene Names: ITGB7
UniProt & NIH Common Fund Data Resources
Find proteins for P26010 (Homo sapiens)
Explore P26010
Go to UniProtKB:  P26010
PHAROS:  P26010
GTEx:  ENSG00000139626
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP26010
Glycosylation
Glycosylation Sites: 1Go to GlyGen: P26010-1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Cadherin-1331Homo sapiensMutation(s): 0
Gene Names: CDH1CDHEUVO
UniProt & NIH Common Fund Data Resources
Find proteins for P12830 (Homo sapiens)
Explore P12830
Go to UniProtKB:  P12830
PHAROS:  P12830
GTEx:  ENSG00000039068
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP12830
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 4
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
D, E
3N-Glycosylation
Glycosylation Resources
GlyTouCan:  G15407YE
GlyCosmos:  G15407YE
GlyGen:  G15407YE
Entity ID: 5
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
F
2N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAG
Query on NAG

Download Ideal Coordinates CCD File
G [auth A],
H [auth A],
M [auth B]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
MN
Query on MN

Download Ideal Coordinates CCD File
L [auth A],
N [auth B],
O [auth B],
P [auth B]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
I [auth A],
J [auth A],
K [auth A]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.37 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.20.1_4487
RECONSTRUCTIONcryoSPARC

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35GM147414
National Science Foundation (NSF, United States)United States--
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesT32GM008268

Revision History  (Full details and data files)

  • Version 1.0: 2025-09-24
    Type: Initial release
