9MFO | pdb_00009mfo

Human DHX9 in Complex with Compound 1 and ADP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.26 Å
  • R-Value Free:
    0.288 (Depositor), 0.289 (DCC)
  • R-Value Work:
    0.236 (Depositor), 0.236 (DCC)
  • R-Value Observed:
    0.238 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Discovery of ATX968: An Orally Available Allosteric Inhibitor of DHX9.

Daniels, M.H.Castro, J.Lee, Y.T.Gotur, D.Knockenhauer, K.E.Grigoriu, S.Lockbaum, G.J.Cheong, J.E.Lu, C.Brennan, D.Buker, S.M.Liu, J.Yao, S.Sparling, B.A.Sickmier, E.A.Ribich, S.Blakemore, S.J.Silver, S.J.Boriack-Sjodin, P.A.Duncan, K.W.Copeland, R.A.

(2025) J Med Chem 68: 9537-9554

  • DOI: https://doi.org/10.1021/acs.jmedchem.5c00252
  • Primary Citation of Related Structures:
    9MFO, 9MFP, 9MFQ, 9MFR, 9MFS, 9MFT

  • PubMed Abstract:

    DHX9 is an RNA/DNA helicase integral in the maintenance of genome stability that has emerged as an attractive target for oncology drug discovery. Disclosed herein is the discovery and optimization of a series of DHX9 inhibitors. Compound 1 was identified as a partial inhibitor of DHX9 ATPase activity but a full inhibitor of unwinding activity. Binding of 1 to a pocket distinct from the ATP binding site was confirmed by X-ray crystallography, enabling structure-based drug optimization. During this optimization, a sulfur-halogen bond was identified that increased on-target residence time without impacting equilibrium binding affinity. Analysis shows that cell potency more closely correlates with residence time than with equilibrium measurements of binding affinity or biochemical potency. Further optimization of potency and ADME properties led to the identification of ATX968 , a potent and selective DHX9 inhibitor that is efficacious in a tumor xenograft model of microsatellite instability-high (MSI-H) colorectal cancer.


  • Organizational Affiliation

    Accent Therapeutics, Inc., 1050 Waltham Street, Lexington, Massachusetts 02421, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
ATP-dependent RNA helicase A1,010Homo sapiensMutation(s): 0
Gene Names: DHX9DDX9LKPNDH2
EC: 3.6.4.13
UniProt & NIH Common Fund Data Resources
Find proteins for Q08211 (Homo sapiens)
Explore Q08211
Go to UniProtKB:  Q08211
PHAROS:  Q08211
GTEx:  ENSG00000135829
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ08211
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ADP
Query on ADP

Download Ideal Coordinates CCD File
C [auth A]ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
A1BK0 (Subject of Investigation/LOI)
Query on A1BK0

Download Ideal Coordinates CCD File
B [auth A]1-ethyl-N-[3-(methanesulfonamido)phenyl]-5-methyl-1H-pyrazole-3-carboxamide
C14 H18 N4 O3 S
RNCRRFDHODBLRY-UHFFFAOYSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
E [auth A],
F [auth A],
G [auth A],
H [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
MG
Query on MG

Download Ideal Coordinates CCD File
D [auth A]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.26 Å
  • R-Value Free:  0.288 (Depositor), 0.289 (DCC)
  • R-Value Work:  0.236 (Depositor), 0.236 (DCC)
  • R-Value Observed: 0.238 (Depositor)
Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 85.52α = 90
b = 85.52β = 90
c = 350.8γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata processing
XDSdata scaling
Aimlessdata reduction
PHASERphasing
Cootmodel building

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2025-05-07
    Type: Initial release
  • Version 1.1: 2025-05-21
    Changes: Database references
