Crystal structure of GAGWLP and PD-L1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:
    0.284 (Depositor), 0.284 (DCC)
  • R-Value Work:
    0.273 (Depositor), 0.273 (DCC)
  • R-Value Observed:
    0.274 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9MAP

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Multicyclic Peptides Targeting PD-L1 for Radiotheranostics: From Discovery to Clinical Proof-of-Concept.

Cheng, X.Jiang, S.Peng, X.Yang, P.Zhang, S.Xu, C.Gao, X.Fan, S.Liu, H.Zhuang, J.Chen, X.Liang, N.Lin, B.Lu, Q.Chen, M.Xiao, Y.Zhu, Z.Wang, R.Hu, K.Wu, C.

(2025) J Am Chem Soc 147: 35638-35654

  • DOI: https://doi.org/10.1021/jacs.5c11292
  • Primary Citation Related Structures:
    9MAP

  • PubMed Abstract:

    Radiotheranostics holds transformative potential for precision oncology by integrating diagnostic imaging with targeted radionuclide therapy. However, advancements in this field are significantly hindered by the limited availability of high-affinity ligands that are capable of engaging challenging cell-surface antigens, particularly flat, low-druggability targets such as programmed death-ligand 1 (PD-L1). Here, we overcome this barrier through de novo discovery and rational engineering of a disulfide-directed multicyclic peptide (DDMP), dmp10, which achieves a picomolar affinity for PD-L1 by leveraging conformationally constrained structural scaffolds. By combining disulfide-directed library design with iterative directed evolution, we successfully generated dmp10, a ∼3 kDa multicyclic peptide that establishes unprecedented shape complementarity to the expansive binding interface of PD-L1. Preclinical evaluations demonstrated that 68 Ga-labeled dmp10 enables high-contrast PET imaging of PD-L1 + tumors in murine models, achieving a tumor uptake of 13.27 %ID/g at 4 h post-injection. The therapeutic counterpart, 177 Lu-labeled dmp10, effectively eradicated 92.47% of established tumors in tumor models while sparing healthy tissues, thereby validating its dual radiotheranostic utility. The translational relevance of our findings was further confirmed in a first-in-human pilot study, where 68 Ga-labeled dmp10 was well tolerated and allowed visualization of PD-L1 + lesions in patients with solid tumors. This work not only establishes DDMPs as a versatile platform for targeting geometrically complex antigens but also delivers a promising radiotheranostic agent that bridges molecular imaging and precision radionuclide therapy for PD-L1-driven malignancies. Our findings advance current strategies for designing ultrahigh-affinity peptide binders and underscore the untapped potential of multicyclic architectures in overcoming longstanding challenges in cancer theranostics.


  • Organizational Affiliation
    • Department of Chemistry, College of Chemistry and Chemical Engineering, The MOE Key Laboratory of Spectrochemical Analysis and Instrumentation, State Key Laboratory of Physical Chemistry of Solid Surfaces, Xiamen University, Xiamen 361005, P.R. China.

Macromolecule Content

  • Total Structure Weight: 17.06 kDa
  • Atom Count: 1,173
  • Modeled Residue Count: 148
  • Deposited Residue Count: 150
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Programmed cell death 1 ligand 1122Homo sapiensMutation(s): 0
Gene Names: CD274B7H1PDCD1L1PDCD1LG1PDL1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NZQ7 (Homo sapiens)
Explore Q9NZQ7
Go to UniProtKB:  Q9NZQ7
PHAROS:  Q9NZQ7
GTEx:  ENSG00000120217
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NZQ7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
G-AGWLP28Homo sapiensMutation(s): 0

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:  0.284 (Depositor), 0.284 (DCC)
  • R-Value Work:  0.273 (Depositor), 0.273 (DCC)
  • R-Value Observed: 0.274 (Depositor)
Space Group: I 41 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 222.605α = 90
b = 222.605β = 90
c = 222.605γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
autoPROCdata reduction
XDSdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China--

Revision History  (Full details and data files)

  • Version 1.0: 2025-12-03
    Type: Initial release
  • Version 1.1: 2026-04-08
    Changes: Database references
