9LNY | pdb_00009lny

Crystal structure of human heavy chain Ferritin binding with dinitrosyl iron complex modificated by phenylboronic acid

PDB DOI: https://doi.org/10.2210/pdb9LNY/pdb

Classification: METAL BINDING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-01-22 Released: 2025-11-26
Deposition Author(s): Gong, W.J., Wang, W.M., Wang, H.F.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free:
0.242 (Depositor), 0.243 (DCC)
R-Value Work:
0.187 (Depositor), 0.206 (DCC)
R-Value Observed:
0.190 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Photoinduced NO release of [Fe2( mu-SL)2(NO)4] complexes and their protein adducts: insights from structure, cytotoxicity, and photodynamic studies

Gong, W., Pang, Y., Wang, C., Wang, W., Wang, H.

(2025) Inorg Chem Front 12: 3490-3504

DOI: https://doi.org/10.1039/D5QI00255A

Macromolecule Content

Total Structure Weight: 20.83 kDa
Atom Count: 1,568
Modeled Residue Count: 171
Deposited Residue Count: 172
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ferritin heavy chain, N-terminally processed	A	172	Homo sapiens	Mutation(s): 0 Gene Names: FTH1, FTH, FTHL6, OK/SW-cl.84, PIG15 EC: 1.16.3.1
UniProt & NIH Common Fund Data Resources
Find proteins for P02794 (Homo sapiens) Explore P02794 Go to UniProtKB: P02794
PHAROS: P02794 GTEx: ENSG00000167996
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P02794
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1EKS (Subject of Investigation/LOI) Query on A1EKS Download Ideal Coordinates CCD File SDF format, chain N [auth A] MOL2 format, chain N [auth A] mmCIF format, chain N [auth A]	N [auth A]	[3-(bromomethyl)phenyl]boronic acid C₇ H₈ B Br O₂ ATRFDLFMCLYROQ-UHFFFAOYSA-N		Interactions Focus chain N [auth A] Interactions & Density Focus chain N [auth A]
FE Query on FE Download Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A]	B [auth A], C [auth A], D [auth A], E [auth A]	FE (III) ION Fe VTLYFUHAOXGGBS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A]	I [auth A], J [auth A], K [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A]
H2S Query on H2S Download Ideal Coordinates CCD File SDF format, chain O [auth A] MOL2 format, chain O [auth A] mmCIF format, chain O [auth A]	O [auth A]	HYDROSULFURIC ACID H₂ S RWSOTUBLDIXVET-UHFFFAOYSA-N		Interactions Focus chain O [auth A] Interactions & Density Focus chain O [auth A]
NO Query on NO Download Ideal Coordinates CCD File SDF format, chain L [auth A] SDF format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A]	L [auth A], M [auth A]	NITRIC OXIDE N O ODUCDPQEXGNKDN-UHFFFAOYSA-N		Interactions Focus chain L [auth A] Focus chain M [auth A] Interactions & Density Focus chain L [auth A] Focus chain M [auth A]
MG Query on MG Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A]	F [auth A], G [auth A], H [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A]
