9L8Y | pdb_00009l8y

Crystal structure of HERC2

  • Classification: LIGASE
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli
  • Mutation(s): No

  • Deposited: 2024-12-28 Released: 2025-11-05
  • Deposition Author(s): Liu, H.B., Pan, L.F.
  • Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.92 Å
  • R-Value Free:
    0.206 (Depositor), 0.205 (DCC)
  • R-Value Work:
    0.180 (Depositor), 0.179 (DCC)
  • R-Value Observed:
    0.181 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Mechanistic insights into the iron-sulfur cluster-dependent interaction of the autophagy receptor NCOA4 with the E3 ligase HERC2.

Liu, H.Shen, L.Gong, X.Zhou, X.Huang, Y.Zhou, Y.Guo, Z.Guo, H.Wang, S.Pan, L.

(2025) Proc Natl Acad Sci U S A 122: e2510269122-e2510269122

  • DOI: https://doi.org/10.1073/pnas.2510269122
  • Primary Citation of Related Structures:
    9L8Y, 9L93

  • PubMed Abstract:

    NCOA4, a dedicated autophagy receptor for mediating selective autophagy of ferritin (ferritinophagy), plays a vital role in maintaining cellular iron homeostasis. The cellular abundance of NCOA4 is regulated by the E3 ligase HERC2 that can specifically target NCOA4 for proteasomal degradation under iron-replete conditions. However, the detailed molecular mechanism governing the iron-dependent recognition of NCOA4 by HERC2 remains elusive. Here, using multidisciplinary approaches, we systematically characterize the HERC2-binding domain (HBD) of NCOA4 and its interaction with HERC2. We uncover that NCOA4 HBD harbors a [2Fe-2S] cluster and can exist in two different states, the apo -form state and the [2Fe-2S] cluster-bound state. Moreover, we unravel that HERC2 can effectively recognize the [2Fe-2S] cluster-bound NCOA4 HBD through its Cullin-7-PARC-HERC2 (CPH) domain and iron-sulfur cluster-dependent NCOA4-binding domain (INBD) with a synergistic binding mode. The determined crystal structures of HERC2(2540-2700) and its complex with the [2Fe-2S] cluster-bound NCOA4 HBD together with relevant biochemical and cellular results not only elucidate how NCOA4 HBD specifically senses cellular iron level by binding a [2Fe-2S] cluster but also reveal the molecular basis underlying the specific interaction of HERC2 with the [2Fe-2S] cluster-bound NCOA4 HBD. In summary, our findings provide mechanistic insights into the iron-dependent turnover of NCOA4 by HERC2 and expand our understanding of the regulatory mechanism of NCOA4-mediated ferritinophagy.


  • Organizational Affiliation
    • State Key Laboratory of Chemical Biology, Shanghai Institute of Organic Chemistry, University of Chinese Academy of Sciences, Chinese Academy of Sciences, Shanghai 200032, China.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
E3 ubiquitin-protein ligase HERC2164Homo sapiensMutation(s): 0
Gene Names: HERC2
EC: 2.3.2.26
UniProt & NIH Common Fund Data Resources
Find proteins for O95714 (Homo sapiens)
Explore O95714
Go to UniProtKB:  O95714
PHAROS:  O95714
GTEx:  ENSG00000128731
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO95714
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.92 Å
  • R-Value Free:  0.206 (Depositor), 0.205 (DCC)
  • R-Value Work:  0.180 (Depositor), 0.179 (DCC)
  • R-Value Observed: 0.181 (Depositor)
Space Group: F 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 63.232α = 90
b = 99.591β = 90
c = 123.297γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
autoPROCdata reduction
autoPROCdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China21822705

Revision History  (Full details and data files)

  • Version 1.0: 2025-11-05
    Type: Initial release
