9KVW | pdb_00009kvw

Crystal Structures of Keap1-compound complexes

  • Classification: PROTEIN BINDING
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli
  • Mutation(s): No

  • Deposited: 2024-12-05 Released: 2025-12-10
  • Deposition Author(s): Zhuang, C.L., Yu, R.L.
  • Funding Organization(s): National Natural Science Foundation of China (NSFC), Ministry of Science and Technology (MoST, China)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.44 Å
  • R-Value Free:
    0.233 (Depositor), 0.237 (DCC)
  • R-Value Work:
    0.216 (Depositor), 0.219 (DCC)
  • R-Value Observed:
    0.217 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9KVW

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Design of spiro-heterocyclic substituted diaminonaphthalene Keap1-Nrf2 protein-protein interaction inhibitors as novel anti-depressant agents.

Chen, Y.Qin, Q.Ding, W.Yu, R.Wang, R.Ji, H.Yan, J.Ma, H.Jiang, C.S.Sun, Y.Zhuang, C.

(2025) Eur J Med Chem 296: 117848-117848

  • DOI: https://doi.org/10.1016/j.ejmech.2025.117848
  • Primary Citation Related Structures:
    9KVW

  • PubMed Abstract:

    Oxidative stress, inflammation and the Keap1-Nrf2 pathway are validated to be related to depression. Theoretically, modulating Keap1 and Nrf2 protein-protein interaction (PPI) should be an effective method to activate Nrf2 for the treatment of major depressive disorders. We previously reported NXPZ-2, a 1,4-diaminonaphthalene, as a Keap1-Nrf2 PPI inhibitor that exhibited promising effects in an Alzheimer's disease (AD) mouse model. However, its pharmacokinetic properties were limited. Herein, we, for the first time, developed a series of heterocyclic substituted diaminonaphthalenes by an "Escape from Flatland" strategy to improve sp 3 hybridized carbons. These compounds exhibited strong binding affinity for Keap1. A crystallographic analysis revealed the high-resolution (1.44 Å) binding of CD-10 with the Keap1 protein, elucidating the complexity of CD-10's binding mechanism. In an LPS-stimulated BV2 cell model, CD-10 demonstrated the best anti-oxidative stress and anti-inflammatory potential. Furthermore, CD-10's ability to penetrate the blood-brain barrier has been significantly improved. In a chronic unpredictable mild stress (CUMS) mouse model, treatment with CD-10 effectively alleviated anxiety and depressive behaviors and restored serum neurotransmitter levels by promoting Nrf2 nuclear translocation. Overall, our findings validate that the Keap1-Nrf2 PPI inhibitor holds promise as a preclinical candidate for the treatment of depression.


  • Organizational Affiliation
    • School of Biological Science and Technology, University of Jinan, Jinan 250022, China; The Center for Basic Research and Innovation of Medicine and Pharmacy (MOE), School of Pharmacy, Second Military Medical University, 325 Guohe Road, Shanghai 200433, China.

Macromolecule Content

  • Total Structure Weight: 32.38 kDa
  • Atom Count: 2,488
  • Modeled Residue Count: 278
  • Deposited Residue Count: 288
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Kelch-like ECH-associated protein 1288Homo sapiensMutation(s): 0
Gene Names: KEAP1INRF2KIAA0132KLHL19
UniProt & NIH Common Fund Data Resources
Find proteins for Q14145 (Homo sapiens)
Explore Q14145
Go to UniProtKB:  Q14145
PHAROS:  Q14145
GTEx:  ENSG00000079999
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ14145
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1EHH
(Subject of Investigation/LOI)

Query on A1EHH



Download:Ideal Coordinates CCD File
B [auth A]~{N}-[4-[(2-azanyl-2-oxidanylidene-ethyl)-[4-[(2-azanyl-2-oxidanylidene-ethyl)-(4-methoxyphenyl)sulfonyl-amino]naphthalen-1-yl]sulfamoyl]phenyl]-3-(2-oxa-8-azaspiro[4.5]decan-8-yl)propanamide
C38 H44 N6 O9 S2
ODOXLPYUODJKBR-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.44 Å
  • R-Value Free:  0.233 (Depositor), 0.237 (DCC)
  • R-Value Work:  0.216 (Depositor), 0.219 (DCC)
  • R-Value Observed: 0.217 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 38.584α = 90
b = 72.958β = 100.6
c = 48.057γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data scaling
HKL-3000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China82022065
Ministry of Science and Technology (MoST, China)China2021YFA1302200

Revision History  (Full details and data files)

  • Version 1.0: 2025-12-10
    Type: Initial release
  • Version 1.1: 2026-06-24
    Changes: Database references
