9KGB | pdb_00009kgb

Crystal structure of tolypothrichol synthase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.76 Å
  • R-Value Free:
    0.224 (Depositor), 0.231 (DCC)
  • R-Value Work:
    0.179 (Depositor), 0.190 (DCC)
  • R-Value Observed:
    0.181 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Mechanistic Characterization of Diterpene Synthase Pairs for Tricyclic Diterpenes from Cyanobacteria.

Yu, J.Shiraishi, T.Taizoumbe, K.A.Karasuno, Y.Yoshida, A.Nishiyama, M.Dickschat, J.S.Kuzuyama, T.

(2025) J Am Chem Soc 147: 11896-11905

  • DOI: https://doi.org/10.1021/jacs.4c16710
  • Primary Citation of Related Structures:
    9KGB

  • PubMed Abstract:

    In recent years, genome mining in cyanobacteria has revealed abundant gene clusters related to natural product biosynthesis. However, only a few terpene synthases (TSs) have been identified from this bacterial phylum. Pfam profiles, such as PF03936 and PF19086, which are frequently used for TS retrieval, are built from plant, bacterial, and fungal TSs. Herein, we constructed a new hidden Markov model (HMM) specific to bacterial TSs on the basis of 110 bacterial TSs experimentally validated in recent years. Using this model, we identified a pair of diterpene synthases, Cpt11 (class II TS) and Cts11 (class I TS), in the cyanobacterium Scytonema tolypothrichoides . In vitro experiments demonstrated that Cpt11 catalyzes the formation of syn -copalyl diphosphate from geranylgeranyl diphosphate and that Cts11 subsequently converts syn -copalyl diphosphate into a rare 6,6,7-tricyclic diterpene alcohol. Its biosynthesis was established through isotope labeling experiments, which revealed a unique sequence of a 1,6-proton shift and ring expansion to a seven-membered ring. We solved the crystal structure of Cts11 at a resolution of 1.76 Å. Additionally, via site-directed mutagenesis experiments, we identified two amino acid residues whose exchanges affected the formation of the original diterpene alcohol, leading to the formation of two new compounds: a 6,6,7-tricyclic diterpene hydrocarbon and another 6,6,6-tricyclic diterpene alcohol. A BLAST search revealed several sequences that shared over 70% identity with Cts11 from cyanobacteria that could produce diverse diterpenes. This study demonstrates the potential for cyanobacteria to produce unprecedented terpenoids and lays the foundation for studying the physiological activities of terpenoids in cyanobacteria.


  • Organizational Affiliation

    Graduate School of Agricultural and Life Sciences, The University of Tokyo, 1-1-1 Yayoi, Bunkyo-ku, Tokyo 113-8657, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
terpene synthase377Scytonema tolypothrichoides VB-61278Mutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
B [auth A]SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.76 Å
  • R-Value Free:  0.224 (Depositor), 0.231 (DCC)
  • R-Value Work:  0.179 (Depositor), 0.190 (DCC)
  • R-Value Observed: 0.181 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 49.155α = 90
b = 55.77β = 90.75
c = 57.66γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata scaling
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of Science (JSPS)Japan22H05120

Revision History  (Full details and data files)

  • Version 1.0: 2025-04-09
    Type: Initial release
  • Version 1.1: 2025-04-16
    Changes: Database references
