9KFX | pdb_00009kfx

Crystal structure of synthetic PPR-DYW in complex with target RNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:
    0.243 (Depositor), 0.238 (DCC)
  • R-Value Work:
    0.199 (Depositor), 0.194 (DCC)
  • R-Value Observed:
    0.200 (Depositor)

Starting Models: experimental, in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9KFX

This is version 2.1 of the entry. See complete history

Literature

Structural basis of plant organelle C-to-U RNA editing by PPR-DYW proteins.

Teramoto, T.Urushihara, R.Aoyama, R.Okada, A.Ichinose, M.Yagi, Y.Nakamura, T.Gutmann, B.Kakuta, Y.

(2026) Nat Commun

  • DOI: https://doi.org/10.1038/s41467-026-72391-y
  • Primary Citation Related Structures:
    9KFX, 9KFY

  • PubMed Abstract:

    Plants possess a unique C-to-U RNA editing mechanism mediated by PPR-DYW proteins, wherein the PPR domain recognizes specific RNA sequences while the DYW deaminase domain precisely edits the target C base-a process essential for functional protein expression in plant chloroplasts and mitochondria. The coordination of these two domains is considered crucial for precise RNA editing. In nature, this site-specific and precise base editing by PPR-DYW proteins distinguishes them from other base-editing deaminases. However, the absence of structures containing both PPR and DYW domains has limited our understanding of the precise RNA-editing mechanism of PPR-DYW proteins. Here, we present crystal structures of the consensus PPR-DYW (consPPR-DYW) protein, a representative of the PPR-DYW proteins, in both RNA-free and target RNA-bound states. Comparison between these states demonstrates domain movements upon target RNA binding, whereby the PPR domain accommodates the upstream sequence of the target C base in the proper conformation for editing while the DYW domain is optimally positioned for precise C-to-U conversion. These results, combined with comprehensive biochemical analyses, provide the foundation for a mechanistic model that explains the coordinated action of the PPR and DYW domains in achieving precise C-to-U editing.


  • Organizational Affiliation
    • Laboratory of Biophysical Chemistry, Department of Bioscience and Biotechnology, Faculty of Agriculture, Kyushu University, Fukuoka, Japan. teramotot@agr.kyushu-u.ac.jp.

Macromolecule Content

  • Total Structure Weight: 148.53 kDa
  • Atom Count: 10,444
  • Modeled Residue Count: 1,262
  • Deposited Residue Count: 1,262
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Synthetic PPR-DYW protein
A, B
612synthetic constructMutation(s): 0
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
rpoA RNA (5'-R(*UP*UP*AP*CP*AP*CP*GP*UP*GP*CP*AP*AP*AP*AP*UP*CP*UP*G)-3')C [auth R],
D [auth r]
18Arabidopsis thaliana
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:  0.243 (Depositor), 0.238 (DCC)
  • R-Value Work:  0.199 (Depositor), 0.194 (DCC)
  • R-Value Observed: 0.200 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 103.66α = 90
b = 109.35β = 90
c = 187.41γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2025-11-12
    Type: Initial release
  • Version 2.0: 2026-01-21
    Type: Coordinate replacement
    Reason: Model completeness
    Changes: Atomic model, Author supporting evidence, Data collection, Derived calculations, Refinement description, Structure summary
  • Version 2.1: 2026-06-03
    Changes: Database references
