9K1N | pdb_00009k1n

Crystal structure of family 11 xylanase in complex with inhibitor (OsXIP)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.21 Å
  • R-Value Free:
    0.317 (Depositor), 0.318 (DCC)
  • R-Value Work:
    0.267 (Depositor), 0.268 (DCC)
  • R-Value Observed:
    0.270 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Molecular arrangements that accompany binding of rice xylanase inhibitor protein OsXIP and the Rhizopus oryzae GH11 xylanase RXyn2.

Ohnuma, T.Tanaka, J.Ozaki, H.Mitsui, K.Tsujitsugu, D.Okugawa, M.Takeda, T.Ihara, M.Fukamizo, T.Takeshita, D.

(2025) J Biological Chem 301: 110385-110385

  • DOI: https://doi.org/10.1016/j.jbc.2025.110385
  • Primary Citation of Related Structures:
    9K1M, 9K1N

  • PubMed Abstract:

    Plants have evolved xylanase inhibitor proteins as part of their defense mechanisms against phytopathogens. The rice xylanase inhibitor protein (OsXIP) is structurally similar to GH18 chitinase and homologous to wheat XIP-type inhibitor (XIP-I), which inhibits both GH10 and GH11 xylanases. Various inhibition and interaction analyses showed that OsXIP competitively inhibits the hydrolytic activity of GH11 xylanase RXyn2, but not the activity of GH10 xylanase RXyn1 from Rhizopus oryzae. The crystal structure of the OsXIP/RXyn2 complex showed that OsXIP, which has a (β/α) 8 -barrel fold, extrudes the loop between α4 and β5 (Lα4β5 OsXIP ) and inserts the loop into the xylotriose binding site (-3 to -1 subsite) formed by the inner β-sheet (palm) of RXyn2 jelly roll. The guanidyl group of Arg155 in Lα4β5 OsXIP was shown to be critical for the inhibitory activity by mutational analysis. Notably, in the complex structure, the cylindrical cavity formed by the palm of RXyn2 jelly roll stacked upright on the loops at the N terminal ends of the β-strands of OsXIP (I-formation). On the other hand, in the complex structure of XIP-I and GH11 xylanase from Talaromyces funiculosus (XYNC), the cavity of XYNC laid tangentially to the part of the corresponding region of XIP-I through the Lα4β5 XIP-I (T-formation). The dissociation constant of the OsXIP/RXyn2 complex was one-tenth of that of the XIP-I/XYNC complex (4.2 versus 41.5 nM). OsXIP may have adapted to bind and inhibit GH11 enzymes, which are resistant to the inhibition by XIP-I type proteins, by changing its binding mode.


  • Organizational Affiliation
    • Department of Advanced Bioscience, Kindai University, Nara, Japan; Agricultural Technology and Innovation Research Institute, Nara, Japan. Electronic address: ohnumat@nara.kindai.ac.jp.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Endo-1,4-beta-xylanase 2A [auth C],
B [auth D]
204Rhizopus arrhizusMutation(s): 0
Gene Names: xyn2
EC: 3.2.1.8
UniProt
Find proteins for W0HJ53 (Rhizopus oryzae)
Explore W0HJ53
Go to UniProtKB:  W0HJ53
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupW0HJ53
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Xylanase inhibitor protein XIPC [auth B],
D [auth A]
279Oryza sativa Japonica GroupMutation(s): 0
Gene Names: XIPOs05g0247800LOC_Os05g15880OJ1037_G10.8OsJ_17793
UniProt
Find proteins for Q5WMW5 (Oryza sativa subsp. japonica)
Explore Q5WMW5
Go to UniProtKB:  Q5WMW5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5WMW5
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.21 Å
  • R-Value Free:  0.317 (Depositor), 0.318 (DCC)
  • R-Value Work:  0.267 (Depositor), 0.268 (DCC)
  • R-Value Observed: 0.270 (Depositor)
Space Group: I 4 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 197.555α = 90
b = 197.555β = 90
c = 136.323γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of Science (JSPS)Japan19K05834

Revision History  (Full details and data files)

  • Version 1.0: 2025-09-03
    Type: Initial release
