9JTX | pdb_00009jtx

Factor inhibiting HIF-1 alpha in complex with Zn(II) and 2-(4-hydroxy-2-oxo-1-(thiazol-4-ylmethoxy)-1,2-dihydroquinoline-3-carboxamido)-2-methylpropanoic acid


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.08 Å
  • R-Value Free:
    0.247 (Depositor), 0.253 (DCC)
  • R-Value Work:
    0.214 (Depositor), 0.220 (DCC)
  • R-Value Observed:
    0.216 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Derivatives of the Clinically Used HIF Prolyl Hydroxylase Inhibitor Desidustat Are Efficient Inhibitors of Human gamma-Butyrobetaine Hydroxylase.

Corner, T.P.Tumber, A.Salah, E.Jabbary, M.Nakashima, Y.Schnaubelt, L.I.Basak, S.Alshref, F.M.Brewitz, L.Schofield, C.J.

(2025) J Med Chem 68: 9777-9798

  • DOI: https://doi.org/10.1021/acs.jmedchem.5c00586
  • Primary Citation of Related Structures:
    9JTX

  • PubMed Abstract:

    The 2-oxoglutarate (2OG)/Fe(II)-dependent γ-butyrobetaine hydroxylase (BBOX) catalyzes the final step in l-carnitine biosynthesis, i.e. , stereoselective C-3 oxidation of γ-butyrobetaine (GBB). BBOX inhibition is a validated clinical strategy to modulate l-carnitine levels and to enhance cardiovascular efficiency. Reported BBOX inhibitors, including the clinically used cardioprotective agent Mildronate, manifest moderate inhibitory activity in vitro , limited selectivity, and/or unfavorable physicochemical properties, indicating a need for improved BBOX inhibitors. We report that the clinically used hypoxia-inducible factor-α prolyl residue hydroxylase (PHD) inhibitors Desidustat, Enarodustat, and Vadadustat efficiently inhibit isolated recombinant BBOX, suggesting that BBOX inhibition by clinically used PHD inhibitors should be considered as a possible off-target effect. Structure-activity relationship studies on the Desidustat scaffold enabled development of potent BBOX inhibitors that manifest high levels of selectivity for BBOX inhibition over representative human 2OG oxygenases, including PHD2. The Desidustat derivatives will help to enable investigations into the biological roles of l-carnitine and the therapeutic potential of BBOX inhibition.


  • Organizational Affiliation
    • Chemistry Research Laboratory, Department of Chemistry and the Ineos Oxford Institute for Antimicrobial Research, University of Oxford, 12 Mansfield Road, Oxford OX1 3TA, U.K.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Hypoxia-inducible factor 1-alpha inhibitor349Homo sapiensMutation(s): 0
Gene Names: HIF1ANFIH1
EC: 1.14.11.30 (PDB Primary Data), 1.14.11 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NWT6 (Homo sapiens)
Explore Q9NWT6
Go to UniProtKB:  Q9NWT6
PHAROS:  Q9NWT6
GTEx:  ENSG00000166135
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NWT6
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1L4V (Subject of Investigation/LOI)
Query on A1L4V

Download Ideal Coordinates CCD File
E [auth A]2-methyl-2-[[4-oxidanyl-2-oxidanylidene-1-(1,3-thiazol-4-ylmethoxy)quinolin-3-yl]carbonylamino]propanoic acid
C18 H17 N3 O6 S
ZSGOHVBQHOCPMG-UHFFFAOYSA-N
SO4 (Subject of Investigation/LOI)
Query on SO4

Download Ideal Coordinates CCD File
B [auth A]
C [auth A]
D [auth A]
G [auth A]
H [auth A]
B [auth A],
C [auth A],
D [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
ZN (Subject of Investigation/LOI)
Query on ZN

Download Ideal Coordinates CCD File
F [auth A]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.08 Å
  • R-Value Free:  0.247 (Depositor), 0.253 (DCC)
  • R-Value Work:  0.214 (Depositor), 0.220 (DCC)
  • R-Value Observed: 0.216 (Depositor)
Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 86.577α = 90
b = 86.577β = 90
c = 145.177γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
xia2data reduction
xia2data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/J003018/1
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/R000344/1
Wellcome TrustUnited Kingdom106244/Z/14/Z
Cancer Research UKUnited KingdomC8717/A18245

Revision History  (Full details and data files)

  • Version 1.0: 2025-04-30
    Type: Initial release
  • Version 1.1: 2025-05-21
    Changes: Database references
