9JMJ | pdb_00009jmj

Cryo-EM structure of the GD-BatCoV (BtCoV/Ii/GD/2014-422) RBD in complex with human DPP4


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.40 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structures and receptor binding activities of merbecovirus spike proteins reveal key signatures for human DPP4 adaptation.

Yuan, H.Wang, J.Ma, Y.Li, Z.Gao, X.Habib, G.Liu, B.Chen, J.He, J.Zhou, P.Shi, Z.L.Chen, X.Xiong, X.

(2025) Sci Adv 11: eadv7296-eadv7296

  • DOI: https://doi.org/10.1126/sciadv.adv7296
  • Primary Citation of Related Structures:
    9JMF, 9JMG, 9JMH, 9JMI, 9JMJ, 9JMM, 9JMN, 9JMO, 9JMP

  • PubMed Abstract:

    Merbecoviruses from bats, pangolins, and hedgehogs pose significant zoonotic threats, with a limited understanding of receptor binding by their spike (S) proteins. Here, we report cryo-EM structures of GD-BatCoV (BtCoV-422) and SE-PangolinCoV (MjHKU4r-CoV-1) RBDs in complex with human DPP4 (hDPP4). These structures exhibit a substantial offset in their hDPP4 interaction interfaces, revealing a conserved hydrophobic cluster as a convergent signature of DPP4 binding within the MERS-HKU4 clade of merbecoviruses. Structure-guided mutagenesis demonstrates that favorable interactions are distributed across multiple receptor binding motif (RBM) regions, working synergistically to confer high-affinity hDPP4 binding. Swapping of the merbecovirus RBM regions indicate limited plasticity and interchangeability among these regions. In addition, we report cryo-EM structures of six merbecovirus S-trimers. Structure-based phylogenetics suggests that hDPP4-binding merbecoviruses undergo convergent evolution, while ACE2-binding merbecoviruses exhibit diversification in their binding mechanisms. These findings offer critical insights into merbecovirus receptor utilization, providing a structural understanding for future surveillance.


  • Organizational Affiliation
    • State Key Laboratory of Respiratory Disease, Guangdong Provincial Key Laboratory of Stem Cell and Regenerative Medicine, Guangdong-Hong Kong Joint Laboratory for Stem Cell and Regenerative Medicine, Guangzhou Institutes of Biomedicine and Health, Chinese Academy of Sciences, Guangzhou 510530, China.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Dipeptidyl peptidase 4 soluble form,Isoform 1 of Immunoglobulin heavy constant gamma 1A,
B [auth C]
998Homo sapiensMutation(s): 0
Gene Names: DPP4ADCP2CD26IGHG1
EC: 3.4.14.5
UniProt & NIH Common Fund Data Resources
Find proteins for P01857 (Homo sapiens)
Explore P01857
Go to UniProtKB:  P01857
PHAROS:  P01857
GTEx:  ENSG00000211896
Find proteins for P27487 (Homo sapiens)
Explore P27487
Go to UniProtKB:  P27487
PHAROS:  P27487
GTEx:  ENSG00000197635
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsP01857P27487
Glycosylation
Glycosylation Sites: 8Go to GlyGen: P01857-2P27487-1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Spike glycoprotein,Isoform 1 of Immunoglobulin heavy constant gamma 1C [auth B]502Middle East respiratory syndrome-related coronavirusHomo sapiens
This entity is chimeric
Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for A0A2R4KP93 (Middle East respiratory syndrome-related coronavirus)
Explore A0A2R4KP93
Go to UniProtKB:  A0A2R4KP93
Find proteins for P01857 (Homo sapiens)
Explore P01857
Go to UniProtKB:  P01857
PHAROS:  P01857
GTEx:  ENSG00000211896
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsP01857A0A2R4KP93
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 3
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
D, F, G, H, I
D, F, G, H, I, J, K
2N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Entity ID: 4
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
E
3N-Glycosylation
Glycosylation Resources
GlyTouCan:  G15407YE
GlyCosmos:  G15407YE
GlyGen:  G15407YE
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAG (Subject of Investigation/LOI)
Query on NAG

Download Ideal Coordinates CCD File
L [auth A]
M [auth A]
N [auth A]
O [auth A]
P [auth C]
L [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth C],
Q [auth C],
R [auth C],
S [auth C]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.40 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other governmentSRPG22-002
Other government2021YFA1300903
Other government2022A1515110495

Revision History  (Full details and data files)

  • Version 1.0: 2025-06-18
    Type: Initial release
  • Version 1.1: 2025-07-23
    Changes: Data collection, Database references
