9JEL | pdb_00009jel

The complex structure of Y510-9709 and NET determined with Cryo-EM

• PDB DOI: https://doi.org/10.2210/pdb9JEL/pdb
• EM Map EMD-61420: EMDB EMDataResource

• Classification: MEMBRANE PROTEIN
• Organism(s): Homo sapiens
• Expression System: Homo sapiens
• Mutation(s): No


• Deposited: 2024-09-03 Released: 2025-12-24
• Deposition Author(s): Jia, Y., Gao, B., Tan, J., Yan, C., Zhang, W., Lan, Y.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 2.98 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Limiting phosphonic acid interlayer-perovskite reactivity to stabilize perovskite solar modules

Fei, C., Zhang, Y., Wang, M., Yang, Y., Shi, X., Wang, S., Guo, H., Guo, C., Liu, H., Li, M., Gu, H., Barlow, S., You, W., Wang, M., Marder, S., Huang, J.

(2026) Science

• DOI: https://doi.org/10.1126/science.adz7969

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 69.68 kDa
• Atom Count: 4,491
• Modeled Residue Count: 548
• Deposited Residue Count: 617
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sodium-dependent noradrenaline transporter	A	617	Homo sapiens	Mutation(s): 0  Gene Names: SLC6A2, NAT1, NET1, SLC6A5
UniProt & NIH Common Fund Data Resources
Find proteins for P23975 (Homo sapiens) Explore P23975  Go to UniProtKB:  P23975
PHAROS:  P23975 GTEx:  ENSG00000103546

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
A1EBN	B [auth A]	3-(4-chlorophenyl)-5,6-dihydro-[1,3]thiazolo[2,3-b][1,3]thiazol-4-ium C11 H9 Cl N S2 XBGDFKDRBGVDQS-UHFFFAOYSA-N
CL	C [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 2.98 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX
RECONSTRUCTION	cryoSPARC

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-12-24
Deposition Author(s): Jia, Y., Gao, B., Tan, J., Yan, C., Zhang, W., Lan, Y.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	32341016

Revision History

• Version 1.0: 2025-12-24
  Type: Initial release
