9J9F | pdb_00009j9f

Bovine ABCC1 conformation 1

PDB DOI: https://doi.org/10.2210/pdb9J9F/pdb
EM Map EMD-61270: EMDB EMDataResource

Classification: TRANSPORT PROTEIN
Organism(s): Bos taurus
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2024-08-22 Released: 2025-09-03
Deposition Author(s): Zhong, C., Wang, F., Liu, Z., Yu, G.
Funding Organization(s): Other government

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.13 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Bovine ABCC1 conformation 1

Zhong, C., Wang, F., Liu, Z., Yu, G.

To be published.

Macromolecule Content

Total Structure Weight: 172.07 kDa
Atom Count: 10,487
Modeled Residue Count: 1,400
Deposited Residue Count: 1,530
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Multidrug resistance-associated protein 1	A	1,530	Bos taurus	Mutation(s): 0 Gene Names: ABCC1, MRP1 EC: 7.6.2.2 (PDB Primary Data), 7.6.2.3 (PDB Primary Data)
UniProt
Find proteins for Q8HXQ5 (Bos taurus) Explore Q8HXQ5 Go to UniProtKB: Q8HXQ5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8HXQ5
Glycosylation
Glycosylation Sites: 1	Glycosylation Focus chain A
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.13 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.15.2_3472:

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-09-03

Deposition Author(s):

Funding Organization	Location	Grant Number
Other government	China	C10120180025

Revision History (Full details and data files)

Version 1.0: 2025-09-03
Type: Initial release
