9J14 | pdb_00009j14

Structure of the wild-type AZG2 in Arabidopsis thaliana in the trans-Zeatin-bound state at pH 5.5


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.49 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural basis of cytokinin transport by the Arabidopsis AZG2.

Wei, H.Yang, Z.Liu, H.Ying, W.Gao, Y.Zhu, L.Liu, X.Sun, L.

(2025) Nat Commun 16: 3475-3475

  • DOI: https://doi.org/10.1038/s41467-025-58802-6
  • Primary Citation of Related Structures:
    9J12, 9J13, 9J14, 9J15, 9J16, 9J17

  • PubMed Abstract:

    Cytokinins are adenine derivatives serving as phytohormones, which are essential regulators of plant growth, development, and response to environmental factors. The transport process of cytokinins determines their spatial distributions and is critical to their functions. The AZA-GUANINE RESISTANT (AZG) family member AZG2 in Arabidopsis thaliana has been identified as a cytokinin and purine transporter. Here, we characterize the binding and transport of AZG2 towards the natural cytokinin, trans-zeatin (tZ), as well as adenine. AZG2 structures are determined in both the substrate-unbound, adenine-bound, and tZ-bound states, under both acidic and neutral pH. Key residues involved in substrate binding are identified. Two distinct conformations are observed in the tZ-bound state of AZG2 in the neutral pH. Structural analysis reveals the structural dynamics of AZG2 during cytokinin transport, which fit into the elevator-type transport model. These results provide insights into the molecular mechanism of cytokinin transport in plants.


  • Organizational Affiliation
    • Department of Neurology, The First Affiliated Hospital of USTC, MOE Key Laboratory for Membraneless Organelles and Cellular Dynamics, Hefei National Research Center for Physical Sciences at the Microscale, Center for Advanced Interdisciplinary Science and Biomedicine of IHM, Division of Life Sciences and Medicine, University of Science and Technology of China, Hefei, China.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Adenine/guanine permease AZG2
A, B
530Arabidopsis thalianaMutation(s): 0
Gene Names: AZG2At5g50300K6A12.16
Membrane Entity: Yes
UniProt
Find proteins for Q84MA8 (Arabidopsis thaliana)
Explore Q84MA8
Go to UniProtKB:  Q84MA8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ84MA8
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.49 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.20.1_4487:

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (NSF, China)China32322041, 32321001, 31900885

Revision History  (Full details and data files)

  • Version 1.0: 2025-03-19
    Type: Initial release
  • Version 1.1: 2025-10-01
    Changes: Data collection, Database references
