9I5W | pdb_00009i5w

Structure of mature Activin A from DMSO solvent optimisation of XChem fragment screen

PDB DOI: https://doi.org/10.2210/pdb9I5W/pdb

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-01-28 Released: 2025-02-12
Deposition Author(s): Quambusch, L., Hyvonen, M.
Funding Organization(s): German Research Foundation (DFG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.77 Å
R-Value Free:
0.235 (Depositor), 0.254 (DCC)
R-Value Work:
0.198 (Depositor), 0.208 (DCC)
R-Value Observed:
0.200 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9I5W

This is version 1.0 of the entry. See complete history.

Literature

Structure of mature Activin A

Quambusch, L., Hyvonen, M.

To be published.

Macromolecule Content

Total Structure Weight: 27.03 kDa
Atom Count: 1,943
Modeled Residue Count: 222
Deposited Residue Count: 232
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Inhibin beta A chain	A, B	116	Homo sapiens	Mutation(s): 0 Gene Names: INHBA
UniProt & NIH Common Fund Data Resources
Find proteins for P08476 (Homo sapiens) Explore P08476 Go to UniProtKB: P08476
PHAROS: P08476 GTEx: ENSG00000122641
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P08476
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain N [auth B] SDF format, chain M [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain N [auth B] MOL2 format, chain M [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain N [auth B] mmCIF format, chain M [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A] E [auth A] F [auth A] G [auth A] M [auth B] D [auth A], E [auth A], F [auth A], G [auth A], M [auth B], N [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain M [auth B] Focus chain N [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain M [auth B] Focus chain N [auth B]
DMS Query on DMS Download:Ideal Coordinates CCD File SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain H [auth B] SDF format, chain C [auth A] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain C [auth A] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain H [auth B] mmCIF format, chain C [auth A]	C [auth A] H [auth B] I [auth B] J [auth B] K [auth B] C [auth A], H [auth B], I [auth B], J [auth B], K [auth B], L [auth B]	DIMETHYL SULFOXIDE C₂ H₆ O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Interactions & Density Focus chain C [auth A] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.77 Å
R-Value Free: 0.235 (Depositor), 0.254 (DCC)
R-Value Work: 0.198 (Depositor), 0.208 (DCC)
R-Value Observed: 0.200 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 63.791	α = 90
b = 96.202	β = 90
c = 118.786	γ = 90

Software Package:

Software Name	Purpose
BUSTER	refinement
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-02-12

Deposition Author(s):

Funding Organization	Location	Grant Number
German Research Foundation (DFG)	Germany	505091675

Revision History (Full details and data files)

Version 1.0: 2025-02-12
Type: Initial release
