9HS0 | pdb_00009hs0

Copper-containing nitrite reductase (NirK) from Bradyrhizobium japonicum USDA110


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free:
    0.109 (Depositor), 0.109 (DCC)
  • R-Value Work:
    0.090 (Depositor), 0.090 (DCC)
  • R-Value Observed:
    0.091 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structural insights into the copper-containing nitrite reductase from Bradyrhizobium japonicum USDA110 and its role in the low nitrite reductase activity of rhizobia.

Ramirez, C.S.Tolmie, C.Rivas, M.G.Gonzalez, P.J.Murgida, D.H.Opperman, D.J.Brondino, C.D.Ferroni, F.M.

(2025) Arch Biochem Biophys 770: 110467-110467

  • DOI: https://doi.org/10.1016/j.abb.2025.110467
  • Primary Citation of Related Structures:
    9HS0

  • PubMed Abstract:

    Bradyrhizobium japonicum USDA110 is a widely used microorganism in the formulation of bioinoculants for soybean crops, harboring a copper-containing nitrite reductase with low enzymatic activity. The activity of BjNirK at pH 6.5 was higher compared to that at pH 8.0, regardless of the presence of either physiological or artificial electron donors. Thermal shift assays reveal that the enzyme is more stable at pH 6.5 than at pH 8.0. X-ray structural data reveals that the funnel for substrate entry shows a wider cavity when compared to other class I NirK structures. Furthermore, the presence of an additional channel for proton provision is observed, in addition to the primary and secondary proton channels. The T2Cu active site can accommodate one or two water molecules, resulting in a tetra- or pentacoordinated metal site, respectively. The structural data correlates well with both optical visible and resonance Raman spectroscopies, denoting a strong blue character of the T1Cu site in both solid and solution states. Furthermore, EPR-monitored redox titration reveals that the catalytic rate is not constrained by T1Cu-T2Cu intraprotein electron transfer reaction at either pH 6.5 or pH 8.0. Additionally, bioinformatics studies indicate that the interaction between the enzyme and the electron donor is not pH dependent. These two observations suggest that the low activity of BjNirK is not caused by inefficient donor-enzyme interaction or impaired electron transfer. The present results suggest that the structural architecture and enzyme properties in rhizobia are designed to ensure low activity, a trait that is particularly advantageous for symbiosis.


  • Organizational Affiliation
    • Departamento de Física, Facultad de Bioquímica y Ciencias Biológicas. Universidad Nacional del Litoral (UNL). CONICET, Ciudad Universitaria, Paraje El Pozo, Santa Fe, Santa Fe, S300ZAA, Argentina.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Copper-containing nitrite reductase367Bradyrhizobium diazoefficiens USDA 110Mutation(s): 0
Gene Names: nirK
EC: 1.7.2.1
UniProt
Find proteins for Q89EJ6 (Bradyrhizobium diazoefficiens (strain JCM 10833 / BCRC 13528 / IAM 13628 / NBRC 14792 / USDA 110))
Explore Q89EJ6
Go to UniProtKB:  Q89EJ6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ89EJ6
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free:  0.109 (Depositor), 0.109 (DCC)
  • R-Value Work:  0.090 (Depositor), 0.090 (DCC)
  • R-Value Observed: 0.091 (Depositor)
Space Group: P 21 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 105.808α = 90
b = 105.808β = 90
c = 105.808γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
Aimlessdata scaling
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other governmentArgentinaPICT2020-00522

Revision History  (Full details and data files)

  • Version 1.0: 2025-06-11
    Type: Initial release
