9HIH | pdb_00009hih

Mouse IL-2 fused to S4B6 Fab fragment

PDB DOI: https://doi.org/10.2210/pdb9HIH/pdb

Classification: CYTOKINE/IMMUNE SYSTEM
Organism(s): Rattus norvegicus, Mus musculus
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2024-11-26 Released: 2025-12-10
Deposition Author(s): Blaha, J., Skorepa, O., Vanek, O.
Funding Organization(s): Czech Science Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free:
0.276 (Depositor), 0.273 (DCC)
R-Value Work:
0.235 (Depositor), 0.232 (DCC)
R-Value Observed:
0.238 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Mouse IL-2 fused to S4B6 Fab fragment

Skorepa, O., Blaha, J., Vanek, O.

To be published.

Macromolecule Content

Total Structure Weight: 69.24 kDa
Atom Count: 4,315
Modeled Residue Count: 546
Deposited Residue Count: 640
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
S4B6 VH_C1H	A [auth H]	239	Rattus norvegicus	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
mIL-2_LN35_S4B6_LC	B [auth L]	401	Mus musculus	Mutation(s): 0 Gene Names: Il2, Il-2, ENSRNOG00000068865
UniProt
Find proteins for P04351 (Mus musculus) Explore P04351 Go to UniProtKB: P04351
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P04351
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free: 0.276 (Depositor), 0.273 (DCC)
R-Value Work: 0.235 (Depositor), 0.232 (DCC)
R-Value Observed: 0.238 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.866	α = 90
b = 77.004	β = 90
c = 169.659	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
SIMBAD	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-12-10

Deposition Author(s):

Funding Organization	Location	Grant Number
Czech Science Foundation	Czech Republic	20-13029S

Revision History (Full details and data files)

Version 1.0: 2025-12-10
Type: Initial release
