9HBB | pdb_00009hbb

Recombinant tau PHF filaments (peptide synthesis 291-391)

  • Classification: PROTEIN FIBRIL
  • Organism(s): Homo sapiens
  • Mutation(s): No

  • Deposited: 2024-11-06 Released: 2024-11-13
  • Deposition Author(s): Lovestam, S.
  • Funding Organization(s): National Institutes of Health/National Institute on Aging (NIH/NIA)

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.00 Å
  • Aggregation State: FILAMENT
  • Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

Validation slider image for 9HBB

This is version 1.1 of the entry. See complete history

Literature

Post-Translational Modifications Control Phase Transitions of Tau.

Powell, W.C.Nahum, M.Pankratz, K.Herlory, M.Greenwood, J.Poliyenko, D.Holland, P.Jing, R.Biggerstaff, L.Stowell, M.H.B.Walczak, M.A.

(2024) bioRxiv

  • DOI: https://doi.org/10.1101/2024.03.08.583040
  • Primary Citation Related Structures:
    9HBB

  • PubMed Abstract:

    The self-assembly of Tau(297-391) into filaments, which mirror the structures observed in Alzheimer's disease (AD) brains, raises questions about the role of AD-specific post-translational modifications (PTMs) in the formation of paired helical filaments (PHFs). To investigate this, we developed a synthetic approach to produce Tau(291-391) featuring N-acetyllysine, phosphoserine, phosphotyrosine, and N-glycosylation at positions commonly modified in post-mortem AD brains, thus facilitating the study of their roles in Tau pathology. Using transmission electron microscopy (TEM), cryo-electron microscopy (cryo-EM), and a range of optical microscopy techniques, we discovered that these modifications generally hinder the in vitro assembly of Tau into PHFs. Interestingly, while acetylation's effect on Tau assembly displayed variability, either promoting or inhibiting phase transitions in the context of cofactor free aggregation, heparin-induced aggregation, and RNA-mediated liquid-liquid phase separation (LLPS), phosphorylation uniformly mitigated these processes. Our observations suggest that PTMs, particularly those situated outside the fibril's rigid core are pivotal in the nucleation of PHFs. Moreover, in scenarios involving heparin-induced aggregation leading to the formation of heterogeneous aggregates, most AD-specific PTMs, except for K311, appeared to decelerate the aggregation process. The impact of acetylation on RNA-induced LLPS was notably site-dependent, exhibiting both facilitative and inhibitory effects, whereas phosphorylation consistently reduced LLPS across all proteoforms examined. These insights underscore the complex interplay between site-specific PTMs and environmental factors in modulating Tau aggregation kinetics, enhancing our understanding of the molecular underpinnings of Tau pathology in AD and highlighting the critical role of PTMs located outside the ordered filament core in driving the self-assembly of Tau into PHF structures.


  • Organizational Affiliation
    • Department of Chemistry, University of Colorado, Boulder, Colorado 80309, United States.

Macromolecule Content

  • Total Structure Weight: 64.76 kDa
  • Atom Count: 3,468
  • Modeled Residue Count: 456
  • Deposited Residue Count: 606
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Isoform Tau-F of Microtubule-associated protein tau
A, B, C, D, E
A, B, C, D, E, F
101Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P10636 (Homo sapiens)
Explore P10636
Go to UniProtKB:  P10636
PHAROS:  P10636
GTEx:  ENSG00000186868
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP10636
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.00 Å
  • Aggregation State: FILAMENT
  • Reconstruction Method: HELICAL

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data

  • Released Date: 2024-11-13
  • Deposition Author(s): Lovestam, S.

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute on Aging (NIH/NIA)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2024-11-13
    Type: Initial release
  • Version 1.1: 2024-11-20
    Changes: Data collection, Database references
