9FRR | pdb_00009frr

Caspase recruitment domain (CARD)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:
    0.208 (Depositor), 0.209 (DCC)
  • R-Value Work:
    0.184 (Depositor), 0.184 (DCC)
  • R-Value Observed:
    0.185 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9FRR

This is version 1.2 of the entry. See complete history

Literature

CARD domains mediate anti-phage defence in bacterial gasdermin systems.

Wein, T.Millman, A.Lange, K.Yirmiya, E.Hadary, R.Garb, J.Melamed, S.Amitai, G.Dym, O.Steinruecke, F.Hill, A.B.Kranzusch, P.J.Sorek, R.

(2025) Nature 639: 727-734

  • DOI: https://doi.org/10.1038/s41586-024-08498-3
  • Primary Citation Related Structures:
    9CS7, 9CS8, 9FRR

  • PubMed Abstract:

    Caspase recruitment domains (CARDs) and pyrin domains are important facilitators of inflammasome activity and pyroptosis 1 . Following pathogen recognition by nucleotide binding-domain, leucine-rich, repeat-containing (NLR) proteins, CARDs recruit and activate caspases, which, in turn, activate gasdermin pore-forming proteins to induce pyroptotic cell death 2 . Here we show that CARD domains are present in defence systems that protect bacteria against phage. The bacterial CARD domain is essential for protease-mediated activation of certain bacterial gasdermins, which promote cell death once phage infection is recognized. We further show that multiple anti-phage defence systems use CARD domains to activate a variety of cell death effectors, and that CARD domains mediate protein-protein interactions in these systems. We find that these systems are triggered by a conserved immune-evasion protein used by phages to overcome the bacterial defence system RexAB 3 , demonstrating that phage proteins inhibiting one defence system can activate another. Our results suggest that CARD domains represent an ancient component of innate immune systems conserved from bacteria to humans, and that CARD-dependent activation of gasdermins is shared in organisms across the tree of life.


  • Organizational Affiliation
    • Department of Molecular Genetics, Weizmann Institute of Science, Rehovot, Israel.

Macromolecule Content

  • Total Structure Weight: 21.21 kDa
  • Atom Count: 1,628
  • Modeled Residue Count: 185
  • Deposited Residue Count: 190
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Probable serine protease FE772_23065
A, B
95Lysobacter enzymogenesMutation(s): 1
Gene Names: FE772_23065Ga0399710_4915GLE_4745
EC: 3.4.21
UniProt
Find proteins for A0A0S2DN74 (Lysobacter enzymogenes)
Explore A0A0S2DN74
Go to UniProtKB:  A0A0S2DN74
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0S2DN74
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:  0.208 (Depositor), 0.209 (DCC)
  • R-Value Work:  0.184 (Depositor), 0.184 (DCC)
  • R-Value Observed: 0.185 (Depositor)
Space Group: P 65
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 58.414α = 90
b = 58.414β = 90
c = 122.111γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
CrysalisProdata reduction
CrysalisProdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
European Research Council (ERC)European UnionERC-AdG GA 101018520

Revision History  (Full details and data files)

  • Version 1.0: 2025-01-29
    Type: Initial release
  • Version 1.1: 2025-02-12
    Changes: Database references
  • Version 1.2: 2025-03-26
    Changes: Database references
