9FL9 | pdb_00009fl9

Cryo-EM structure of the human KEOPS complex

• PDB DOI: https://doi.org/10.2210/pdb9FL9/pdb
• EM Map EMD-50536: EMDB EMDataResource

• Classification: RNA BINDING PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2024-06-04 Released: 2025-12-17
• Deposition Author(s): Cirio, C., Fernandes, C.A.H., Venien-Bryan, C., Collinet, B., Van Tilbeurgh, H.
• Funding Organization(s): Agence Nationale de la Recherche (ANR)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.74 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental

Literature

Cryo-EM structure of the human KEOPS complex

Cirio, C., Auxilien, S., Liger, D., Fernandes, C.A.H., Dammak, R., Venien-Bryan, C., Mollet, G., Zelie, E., Malhao, M., Arteni, A.A., Touboul, D., Antignac, C., Missoury, S., Van Tilbeurgh, H., Collinet, B.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 5-mer - A1B1C1D1E1

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 114.24 kDa
• Atom Count: 6,769
• Modeled Residue Count: 872
• Deposited Residue Count: 1,038
• Unique protein chains: 5

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
EKC/KEOPS complex subunit TPRKB	A	188	Homo sapiens	Mutation(s): 0  Gene Names: TPRKB, CGI-121, My019
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y3C4 (Homo sapiens) Explore Q9Y3C4  Go to UniProtKB:  Q9Y3C4
PHAROS:  Q9Y3C4 GTEx:  ENSG00000144034

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
EKC/KEOPS complex subunit TP53RK	B	266	Homo sapiens	Mutation(s): 0  Gene Names: TP53RK, C20orf64, PRPK EC: 3.6 (PDB Primary Data), 2.7.11.1 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q96S44 (Homo sapiens) Explore Q96S44  Go to UniProtKB:  Q96S44
PHAROS:  Q96S44 GTEx:  ENSG00000172315

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable tRNA N6-adenosine threonylcarbamoyltransferase	C	335	Homo sapiens	Mutation(s): 0  Gene Names: OSGEP, GCPL1 EC: 2.3.1.234
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NPF4 (Homo sapiens) Explore Q9NPF4  Go to UniProtKB:  Q9NPF4
PHAROS:  Q9NPF4 GTEx:  ENSG00000092094

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
EKC/KEOPS complex subunit LAGE3	D	143	Homo sapiens	Mutation(s): 0  Gene Names: LAGE3, DXS9879E, ESO3, ITBA2
UniProt & NIH Common Fund Data Resources
Find proteins for Q14657 (Homo sapiens) Explore Q14657  Go to UniProtKB:  Q14657
PHAROS:  Q14657 GTEx:  ENSG00000196976

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
EKC/KEOPS complex subunit GON7	E	106	Homo sapiens	Mutation(s): 0  Gene Names: GON7, C14orf142
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BXV9 (Homo sapiens) Explore Q9BXV9  Go to UniProtKB:  Q9BXV9
PHAROS:  Q9BXV9 GTEx:  ENSG00000170270

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.74 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC	4.2.1
MODEL REFINEMENT	PHENIX	1.20.1_4487

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2025-12-17
Deposition Author(s): Cirio, C., Fernandes, C.A.H., Venien-Bryan, C., Collinet, B., Van Tilbeurgh, H.

---

Funding Organization	Location	Grant Number
Agence Nationale de la Recherche (ANR)	France	--

Revision History

• Version 1.0: 2025-12-17
  Type: Initial release
