9FKZ | pdb_00009fkz

Discovery of a Series of Covalent, Cell Active Bfl-1 Inhibitors


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.68 Å
  • R-Value Free:
    0.339 (Depositor)
  • R-Value Work:
    0.271 (Depositor)
  • R-Value Observed:
    0.274 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9FKZ

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Structure-Based Optimization of a Series of Covalent, Cell Active Bfl-1 Inhibitors.

Lucas, S.C.C.Blackwell, J.H.Borjesson, U.Hargreaves, D.Milbradt, A.G.Bostock, M.J.Ahmed, S.Beaumont, K.Cheung, T.Demanze, S.Gohlke, A.Guerot, C.Haider, A.Kantae, V.Kauffman, G.W.Kinzel, O.Kupcova, L.Lainchbury, M.D.Lamb, M.L.Leon, L.Palisse, A.Sacchetto, C.Storer, R.I.Su, N.Thomson, C.Vales, J.Chen, Y.Hu, X.

(2024) J Med Chem 67: 16455-16479

  • DOI: https://doi.org/10.1021/acs.jmedchem.4c01288
  • Primary Citation Related Structures:
    9FKY, 9FKZ, 9FL0

  • PubMed Abstract:

    Bfl-1, a member of the Bcl-2 family of proteins, plays a crucial role in apoptosis regulation and has been implicated in cancer cell survival and resistance to venetoclax therapy. Due to the unique cysteine residue in the BH3 binding site, the development of covalent inhibitors targeting Bfl-1 represents a promising strategy for cancer treatment. Herein, the optimization of a covalent cellular tool from a lead-like hit using structure based design is described. Informed by a reversible X-ray fragment screen, the strategy to establish interactions with a key glutamic acid residue (Glu78) and optimize binding in a cryptic pocket led to a 1000-fold improvement in biochemical potency without increasing reactivity of the warhead. Compound ( R,R,S )-26 has a k inact /K I of 4600 M -1 s -1 , shows <1 μM caspase activation in a cellular assay and cellular target engagement, and has good physicochemical properties and a promising in vivo profile.


  • Organizational Affiliation
    • Hit Discovery, Discovery Sciences, R&D, AstraZeneca, Cambridge CB2 0AA, U.K.

Macromolecule Content

  • Total Structure Weight: 17.81 kDa
  • Atom Count: 1,286
  • Modeled Residue Count: 151
  • Deposited Residue Count: 152
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Bcl-2-related protein A1152Homo sapiensMutation(s): 0
Gene Names: BCL2A1BCL2L5BFL1GRSHBPA1
UniProt & NIH Common Fund Data Resources
Find proteins for Q16548 (Homo sapiens)
Explore Q16548
Go to UniProtKB:  Q16548
PHAROS:  Q16548
GTEx:  ENSG00000140379
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ16548
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1IDO
(Subject of Investigation/LOI)

Query on A1IDO



Download:Ideal Coordinates CCD File
B [auth A]~{N}-[4-[(1~{R},3~{R})-3-azanylcyclopentyl]oxyphenyl]-~{N}-[(4-chlorophenyl)methyl]prop-2-enamide
C21 H23 Cl N2 O2
RCIGCKKIWRZXFW-YLJYHZDGSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.68 Å
  • R-Value Free:  0.339 (Depositor)
  • R-Value Work:  0.271 (Depositor)
  • R-Value Observed: 0.274 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 40.757α = 90
b = 43.383β = 95.73
c = 43.569γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
Aimlessdata scaling
BUSTERrefinement
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2024-10-02
    Type: Initial release
  • Version 1.1: 2024-10-09
    Changes: Database references, Structure summary
