9EP6 | pdb_00009ep6

Alpha-Galactosaminidase family GH114 from Fusarium solani


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.61 Å
  • R-Value Free:
    0.195 (Depositor), 0.195 (DCC)
  • R-Value Work:
    0.178 (Depositor), 0.178 (DCC)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structures of alpha-galactosaminidases from the CAZy GH114 family and homologs defining a new GH191 family of glycosidases.

Roth, C.Moroz, O.V.Miranda, S.A.D.Jahn, L.Blagova, E.V.Lebedev, A.A.Segura, D.R.Stringer, M.A.Friis, E.P.Franco Cairo, J.P.L.Davies, G.J.Wilson, K.S.

(2025) Acta Crystallogr D Struct Biol 81: 234-251

  • DOI: https://doi.org/10.1107/S2059798325002864
  • Primary Citation of Related Structures:
    9EP5, 9EP6, 9EUX, 9EUZ

  • PubMed Abstract:

    Endo-galactosaminidases are an underexplored family of enzymes involved in the degradation of galactosaminogalactan (GAG) and other galactosamine-containing cationic exopolysaccharides produced by fungi and bacteria. These exopolysaccharides are part of the cell wall and extracellular matrix of microbial communities. Currently, these galactosaminidases are found in three distinct CAZy families: GH114, GH135 and GH166. Despite the widespread occurrence of these enzymes in nearly all bacterial and fungal clades, only limited biochemical and structural data are available for these three groups. To expand our knowledge of endo-galactosaminidases, we selected several sequences predicted to encode endo-galactosaminidases and produced them recombinantly for structural and functional studies. Only very few predicted proteins could be produced in soluble form, and activity against bacterial Pel (pellicle) polysaccharide could only be confirmed for one enzyme. Here, we report the structures of two bacterial and one fungal enzyme. Whereas the fungal enzyme belongs to family GH114, the two bacterial enzymes do not lie in the current GH families but instead define a new family, GH191. During structure solution we realized that crystals of all three enzymes had various defects including twinning and partial disorder, which in the case of a more severe pathology in one of the structures required the design of a specialized refinement/model-building protocol. Comparison of the structures revealed several features that might be responsible for the described activity pattern and substrate specificity compared with other GAG-degrading enzymes.


  • Organizational Affiliation
    • Department for Biomolecular Systems, Carbohydrates Structure and Function, Max Planck Institute of Colloids and Interfaces, Arnimallee 22, 14195 Berlin, Germany.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
alpha-galactosidase
A, B, C
296Fusarium solaniMutation(s): 1
Gene Names: NECHADRAFT_74418
EC: 3.2.1.22
UniProt
Find proteins for C7YJY3 (Fusarium vanettenii (strain ATCC MYA-4622 / CBS 123669 / FGSC 9596 / NRRL 45880 / 77-13-4))
Explore C7YJY3
Go to UniProtKB:  C7YJY3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC7YJY3
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PEG
Query on PEG

Download Ideal Coordinates CCD File
E [auth B],
I [auth C],
J [auth C],
K [auth C]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
D [auth A],
F [auth B],
G [auth B],
H [auth B],
L [auth C]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.61 Å
  • R-Value Free:  0.195 (Depositor), 0.195 (DCC)
  • R-Value Work:  0.178 (Depositor), 0.178 (DCC)
Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 95.569α = 90
b = 95.569β = 90
c = 231.428γ = 120
Software Package:
Software NamePurpose
xia2data reduction
XDSdata reduction
Aimlessdata scaling
MOLREPphasing
REFMACrefinement

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2025-04-23
    Type: Initial release
  • Version 1.1: 2025-05-14
    Changes: Database references
