9E1D

Structure of RyR1 in the primed state in the presence of enprofylline


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.76 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Targeting Ryanodine Receptors with Allopurinol and Xanthine Derivatives for the Treatment of Cardiac and Musculoskeletal Weakness Disorders

Miotto, M.C.

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ryanodine receptor 1A,
F [auth B],
G [auth D],
H [auth C]
5,037Oryctolagus cuniculusMutation(s): 0
UniProt
Find proteins for P11716 (Oryctolagus cuniculus)
Explore P11716
Go to UniProtKB:  P11716
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP11716
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Peptidyl-prolyl cis-trans isomerase FKBP1AB [auth E],
C [auth H],
D [auth G],
E [auth F]
108Oryctolagus cuniculusMutation(s): 0
EC: 5.2.1.8
UniProt
Find proteins for P62943 (Oryctolagus cuniculus)
Explore P62943
Go to UniProtKB:  P62943
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62943
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ATP
Query on ATP

Download Ideal Coordinates CCD File
I [auth A],
M [auth B],
Q [auth D],
U [auth C]
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
A1BD3 (Subject of Investigation/LOI)
Query on A1BD3

Download Ideal Coordinates CCD File
L [auth A],
P [auth B],
T [auth D],
X [auth C]
enprofylline
C8 H10 N4 O2
SIQPXVQCUCHWDI-UHFFFAOYSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
K [auth A],
O [auth B],
S [auth D],
W [auth C]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
J [auth A],
N [auth B],
R [auth D],
V [auth C]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.76 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX
RECONSTRUCTIONcryoSPARC

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2024-10-30
    Type: Initial release
