9DZX | pdb_00009dzx

MHV spike tail heptapeptide complexed with coatomer alpha-WD40 domain

PDB DOI: https://doi.org/10.2210/pdb9DZX/pdb

Classification: PROTEIN TRANSPORT
Organism(s): Schizosaccharomyces pombe, Murine hepatitis virus strain A59
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-10-17 Released: 2025-10-22
Deposition Author(s): Shakya, A.K., Hasan, S.S.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.66 Å
R-Value Free:
0.207 (Depositor), 0.207 (DCC)
R-Value Work:
0.176 (Depositor), 0.177 (DCC)
R-Value Observed:
0.178 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

MHV spike tail heptapeptide complexed with coatomer alpha-WD40 domain

Shakya, A.K., Hasan, S.S.

To be published.

Macromolecule Content

Total Structure Weight: 52.86 kDa
Atom Count: 2,774
Modeled Residue Count: 308
Deposited Residue Count: 451
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative coatomer subunit alpha	A	444	Schizosaccharomyces pombe	Mutation(s): 0 Gene Names: SPBPJ4664.04
UniProt
Find proteins for Q96WV5 (Schizosaccharomyces pombe (strain 972 / ATCC 24843)) Explore Q96WV5 Go to UniProtKB: Q96WV5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q96WV5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
SER-HIS-GLU-ASP	B	7	Murine hepatitis virus strain A59	Mutation(s): 0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain N [auth A] MOL2 format, chain N [auth A] mmCIF format, chain N [auth A]	N [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain N [auth A] Interactions & Density Focus chain N [auth A]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain P [auth A] SDF format, chain O [auth A] SDF format, chain M [auth A] SDF format, chain L [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain P [auth A] MOL2 format, chain O [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain P [auth A] mmCIF format, chain O [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], O [auth A], P [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain O [auth A] Focus chain P [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain O [auth A] Focus chain P [auth A]
