9DQ1 | pdb_00009dq1

Crystal structure of HrmJ from Streptomyces sp. CFMR 7 (HrmJ-ssc) complexed with manganese (II), 2-oxoglutarate and 6-nitronorleucine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.204 (Depositor), 0.202 (DCC)
  • R-Value Work:
    0.174 (Depositor), 0.174 (DCC)
  • R-Value Observed:
    0.176 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9DQ1

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Comparison of a Nonheme Iron Cyclopropanase with a Homologous Hydroxylase Reveals Mechanistic Features Associated with Distinct Reaction Outcomes.

Zheng, Y.C.Li, X.Cha, L.Paris, J.C.Michael, C.Ushimaru, R.Ogasawara, Y.Abe, I.Guo, Y.Chang, W.C.

(2025) J Am Chem Soc 147: 6162-6170

  • DOI: https://doi.org/10.1021/jacs.4c17741
  • Primary Citation Related Structures:
    9DQ0, 9DQ1, 9DQ2, 9DQP, 9DQQ, 9DQR

  • PubMed Abstract:

    Despite the diversity of reactions catalyzed by mononuclear iron and 2-oxoglutarate-dependent enzymes, the factors that lead to diverse reaction outcomes beyond canonical hydroxylation remain elusive. Cyclopropanation reactions are of particular interest not only due to the prevalence of cyclopropane moieties in pharmaceuticals but also due to the chemistry that allows cyclopropanation to outcompete oxygen rebound. HrmJ is one such cyclopropanase from the biosynthetic pathway of hormaomycin; however, a homologue is herein discovered that instead catalyzes C -hydroxylation of the same nitro enolate substrate. These enzymes were reconstituted with Mn(II) and V(IV)═O as mimics of the resting (Fe(II)) and reactive (Fe(IV)═O) intermediate states, respectively. Corresponding crystal structures of the cyclopropanase bound with a substrate imply H atom transfer via an offline π-pathway. In contrast, analogous structural analysis of the hydroxylase implies H atom abstraction likely proceeds through a σ-pathway. Preparation of isotopically labeled substrates and stopped-flow kinetic analyses indicate that while the pro-S hydrogen of C4 is abstracted in both enzymes, the Fe(IV)═O intermediate reacts ca. 17-fold faster in the active site of the hydroxylase, consistent with the mechanistic assignments. These results also support a correlation between the mechanism of H atom transfer and the subsequent fate of the substrate radical once generated. A subtle difference in substrate positioning not only affects the H atom abstraction pathway but also allows the nitro enolate moiety to intercept the resulting substrate radical in the active site of the cyclopropase, thereby facilitating intramolecular C-C bond formation in a stereoselective manner.


  • Organizational Affiliation
    • Department of Chemistry, North Carolina State University, Raleigh, North Carolina 27695, United States.

Macromolecule Content

  • Total Structure Weight: 55.06 kDa
  • Atom Count: 4,187
  • Modeled Residue Count: 452
  • Deposited Residue Count: 472
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
BsmA domain containing protein
A, B
236Streptomyces sp. CFMR 7Mutation(s): 0
Gene Names: ABE83_05625
UniProt
Find proteins for A0ACD6B8T9 (Streptomyces sp. CFMR 7)
Explore A0ACD6B8T9
Go to UniProtKB:  A0ACD6B8T9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ACD6B8T9
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
6HN
(Subject of Investigation/LOI)

Query on 6HN



Download:Ideal Coordinates CCD File
E [auth A],
I [auth A],
L [auth B]
6-nitro-L-norleucine
C6 H12 N2 O4
LMSAJWJHQUHKSX-YFKPBYRVSA-N
AKG

Query on AKG



Download:Ideal Coordinates CCD File
D [auth A],
K [auth B]
2-OXOGLUTARIC ACID
C5 H6 O5
KPGXRSRHYNQIFN-UHFFFAOYSA-N
IOD

Query on IOD



Download:Ideal Coordinates CCD File
F [auth A]
G [auth A]
H [auth A]
M [auth B]
N [auth B]
F [auth A],
G [auth A],
H [auth A],
M [auth B],
N [auth B],
O [auth B],
P [auth B]
IODIDE ION
I
XMBWDFGMSWQBCA-UHFFFAOYSA-M
GOL

Query on GOL



Download:Ideal Coordinates CCD File
R [auth B],
S [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
Q [auth B]1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
MN

Query on MN



Download:Ideal Coordinates CCD File
C [auth A],
J [auth B]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.204 (Depositor), 0.202 (DCC)
  • R-Value Work:  0.174 (Depositor), 0.174 (DCC)
  • R-Value Observed: 0.176 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 44.342α = 90
b = 74.971β = 90.032
c = 87.295γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
CrysalisProdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2025-02-12
    Type: Initial release
  • Version 1.1: 2025-03-05
    Changes: Database references
