9D1V | pdb_00009d1v

Human Beta-B2 Crystallin

PDB DOI: https://doi.org/10.2210/pdb9D1V/pdb

Classification: STRUCTURAL PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-08-07 Released: 2025-08-13
Deposition Author(s): Frkic, R.L., Jackson, C.J.
Funding Organization(s): Australian Research Council (ARC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.262 (Depositor), 0.261 (DCC)
R-Value Work:
0.219 (Depositor), 0.218 (DCC)
R-Value Observed:
0.221 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9D1V

This is version 1.0 of the entry. See complete history.

Literature

Human Beta-B2 Crystallin

Frkic, R.L., Jackson, C.J.

To be published.

Macromolecule Content

Total Structure Weight: 93.81 kDa
Atom Count: 6,233
Modeled Residue Count: 737
Deposited Residue Count: 820
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-crystallin B2	A, B, C, D	205	Homo sapiens	Mutation(s): 0 Gene Names: CRYBB2, CRYB2, CRYB2A
UniProt & NIH Common Fund Data Resources
Find proteins for P43320 (Homo sapiens) Explore P43320 Go to UniProtKB: P43320
PHAROS: P43320 GTEx: ENSG00000244752
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P43320
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain F [auth B] MOL2 format, chain F [auth B] mmCIF format, chain F [auth B]	F [auth B]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain F [auth B] Interactions & Density Focus chain F [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.262 (Depositor), 0.261 (DCC)
R-Value Work: 0.219 (Depositor), 0.218 (DCC)
R-Value Observed: 0.221 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 60.491	α = 90
b = 82.915	β = 90
c = 153.224	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-08-13

Deposition Author(s):

Funding Organization	Location	Grant Number
Australian Research Council (ARC)	Australia	CE200100012
Australian Research Council (ARC)	Australia	CE200100029

Revision History (Full details and data files)

Version 1.0: 2025-08-13
Type: Initial release
