9C66 | pdb_00009c66

Structure of the Mena EVH1 domain bound to the polyproline segment of PTP1B


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.40 Å
  • R-Value Free:
    0.196 (Depositor), 0.200 (DCC)
  • R-Value Work:
    0.187 (Depositor), 0.190 (DCC)
  • R-Value Observed:
    0.188 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Insights into the Interaction Landscape of the EVH1 Domain of Mena.

LaComb, L.Ghosh, A.Bonanno, J.B.Nilson, D.J.Poppel, A.J.Dada, L.Cahill, S.M.Maianti, J.P.Kitamura, S.Cowburn, D.Almo, S.C.

(2024) Biochemistry 63: 2183-2195

  • DOI: https://doi.org/10.1021/acs.biochem.4c00331
  • Primary Citation of Related Structures:
    9C66

  • PubMed Abstract:

    The Enabled/VASP homology 1 (EVH1) domain is a small module that interacts with proline-rich stretches in its ligands and is found in various signaling and scaffolding proteins. Mena, the mammalian homologue of Ena, is involved in diverse actin-associated events, such as membrane dynamics, bacterial motility, and tumor intravasation and extravasation. Two-dimensional (2D) 1 H- 15 N HSQC NMR was used to study Mena EVH1 binding properties, defining the amino acids involved in ligand recognition for the physiological ligands ActA and PCARE, and a synthetic polyproline-inspired small molecule (hereafter inhibitor 6c ). Chemical shift perturbations indicated that proline-rich segments bind in the conserved EVH1 hydrophobic cleft. The PCARE-derived peptide elicited more perturbations compared to the ActA-derived peptide, consistent with a previous report of a structural alteration in the solvent-exposed β7-β8 loop. Unexpectedly, EVH1 and the proline-rich segment of PTP1B did not exhibit NMR chemical shift perturbations; however, the high-resolution crystal structure implicated the conserved EVH1 hydrophobic cleft in ligand recognition. Intrinsic steady-state fluorescence and fluorescence polarization assays indicate that residues outside the proline-rich segment enhance the ligand affinity for EVH1 ( K d = 3-8 μM). Inhibitor 6c displayed tighter binding ( K d ∼ 0.3 μM) and occupies the same EVH1 cleft as physiological ligands. These studies revealed that the EVH1 domain enhances ligand affinity through recognition of residues flanking the proline-rich segments. Additionally, a synthetic inhibitor binds more tightly to the EVH1 domain than natural ligands, occupying the same hydrophobic cleft.


  • Organizational Affiliation
    • Department of Biochemistry, Albert Einstein College of Medicine, 1300 Morris Park Avenue, Bronx, New York 10461, United States.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Protein enabled homolog114Homo sapiensMutation(s): 0
Gene Names: ENAHMENA
UniProt & NIH Common Fund Data Resources
Find proteins for Q8N8S7 (Homo sapiens)
Explore Q8N8S7
Go to UniProtKB:  Q8N8S7
PHAROS:  Q8N8S7
GTEx:  ENSG00000154380
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8N8S7
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
poly-proline segment of PTP1B10Homo sapiensMutation(s): 0
EC: 3.1.3.48
UniProt & NIH Common Fund Data Resources
Find proteins for P18031 (Homo sapiens)
Explore P18031
Go to UniProtKB:  P18031
PHAROS:  P18031
GTEx:  ENSG00000196396
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP18031
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.40 Å
  • R-Value Free:  0.196 (Depositor), 0.200 (DCC)
  • R-Value Work:  0.187 (Depositor), 0.190 (DCC)
  • R-Value Observed: 0.188 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 39.654α = 90
b = 49.072β = 90
c = 54.105γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2024-08-28
    Type: Initial release
  • Version 1.1: 2024-09-11
    Changes: Database references
  • Version 1.2: 2024-10-23
    Changes: Structure summary
