9BHB | pdb_00009bhb

Cryo-EM structure of human monoclonal antibody C74 targeting PFD1235w (CIDRa1.6) PfEMP1


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Broadly inhibitory antibodies to severe malaria virulence proteins.

Reyes, R.A.Raghavan, S.S.R.Hurlburt, N.K.Introini, V.Bol, S.Kana, I.H.Jensen, R.W.Martinez-Scholze, E.Gestal-Mato, M.Lopez-Gutierrez, B.Sanz, S.Bancells, C.Fernandez-Quintero, M.L.Loeffler, J.R.Ferguson, J.A.Lee, W.H.Martin, G.M.Theander, T.G.Lusingu, J.P.A.Minja, D.T.R.Ssewanyana, I.Feeney, M.E.Greenhouse, B.Ward, A.B.Bernabeu, M.Pancera, M.Turner, L.Bunnik, E.M.Lavstsen, T.

(2024) Nature 636: 182-189

  • DOI: https://doi.org/10.1038/s41586-024-08220-3
  • Primary Citation of Related Structures:
    8VDF, 8VDG, 8VDL, 9BHB

  • PubMed Abstract:

    Malaria pathology is driven by the accumulation of Plasmodium falciparum-infected erythrocytes in microvessels 1 . This process is mediated by the polymorphic erythrocyte membrane protein 1 (PfEMP1) adhesion proteins of the parasite. A subset of PfEMP1 variants that bind to human endothelial protein C receptor (EPCR) through their CIDRα1 domains is responsible for severe malaria pathogenesis 2 . A longstanding question is whether individual antibodies can recognize the large repertoire of circulating PfEMP1 variants. Here we describe two broadly reactive and inhibitory human monoclonal antibodies to CIDRα1. The antibodies isolated from two different individuals exhibited similar and consistent EPCR-binding inhibition of diverse CIDRα1 domains, representing five of the six subclasses of CIDRα1. Both antibodies inhibited EPCR binding of both recombinant full-length and native PfEMP1 proteins, as well as parasite sequestration in bioengineered 3D human brain microvessels under physiologically relevant flow conditions. Structural analyses of the two antibodies in complex with three different CIDRα1 antigen variants reveal similar binding mechanisms that depend on interactions with three highly conserved amino acid residues of the EPCR-binding site in CIDRα1. These broadly reactive antibodies are likely to represent a common mechanism of acquired immunity to severe malaria and offer novel insights for the design of a vaccine or treatment targeting severe malaria.


  • Organizational Affiliation
    • Department of Microbiology, Immunology and Molecular Genetics, Long School of Medicine, The University of Texas Health Science Center at San Antonio, San Antonio, TX, USA.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
C74 heavy chainA [auth H]121Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
C74 kappa chainB [auth K]113Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Erythrocyte membrane protein 1, PfEMP1C [auth A]728Plasmodium falciparum 3D7Mutation(s): 0
Gene Names: PF3D7_0425800
UniProt
Find proteins for Q8I098 (Plasmodium falciparum (isolate 3D7))
Explore Q8I098
Go to UniProtKB:  Q8I098
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8I098
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Bill & Melinda Gates FoundationUnited States--
LundbeckfondenDenmark--

Revision History  (Full details and data files)

  • Version 1.0: 2024-10-02
    Type: Initial release
  • Version 1.1: 2024-11-06
    Changes: Data collection, Structure summary
  • Version 1.2: 2024-12-04
    Changes: Data collection, Database references
  • Version 1.3: 2024-12-18
    Changes: Data collection, Database references
  • Version 1.4: 2025-06-04
    Changes: Data collection
