9BAT | pdb_00009bat

Crystal structure of sterol 14 alpha-demethylase (CYP51) from deep-sea fish Coryphaenoides armatus (abyssal grenadier) in the ligand-free state


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:
    0.248 (Depositor), 0.242 (DCC)
  • R-Value Work:
    0.232 (Depositor), 0.232 (DCC)
  • R-Value Observed:
    0.233 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Unique Structural Features Relate to Evolutionary Adaptation of Cytochrome P450 in the Abyssal Zone.

Hargrove, T.Y.Lamb, D.C.Wawrzak, Z.Minasov, G.Goldstone, J.V.Kelly, S.L.Stegeman, J.J.Lepesheva, G.I.

(2025) Int J Mol Sci 26

  • DOI: https://doi.org/10.3390/ijms26125689
  • Primary Citation of Related Structures:
    9BAT

  • PubMed Abstract:

    Cytochromes P450 (CYPs) form one of the largest enzyme superfamilies, with similar structural folds yet biological functions varying from synthesis of physiologically essential compounds to metabolism of myriad xenobiotics. Sterol 14α-demethylases (CYP51s) represent a very special P450 family, regarded as a possible evolutionary progenitor for all currently existing P450s. In metazoans CYP51 is critical for the biosynthesis of sterols including cholesterol. Here we determined the crystal structures of ligand-free CYP51s from the abyssal fish Coryphaenoides armatus and human-. Comparative sequence-structure-function analysis revealed specific structural elements that imply elevated conformational flexibility, uncovering a molecular basis for faster catalytic rates, lower substrate selectivity, and intrinsic resistance to inhibition. In addition, the C. armatus structure displayed a large-scale repositioning of structural segments that, in vivo, are immersed in the endoplasmic reticulum membrane and border the substrate entrance (the FG arm, >20 Å, and the β4 hairpin, >15 Å). The structural distinction of C. armatus CYP51, which is the first structurally characterized deep sea P450, suggests stronger involvement of the membrane environment in regulation of the enzyme function. We interpret this as a co-adaptation of the membrane protein structure with membrane lipid composition during evolutionary incursion to life in the deep sea.


  • Organizational Affiliation
    • Department of Biochemistry, Vanderbilt University School of Medicine, Nashville, TN 37232, USA.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Lanosterol 14-alpha demethylase
A, B
449Coryphaenoides armatusMutation(s): 0
Gene Names: CYP51ERG11
EC: 1.14.14.154
UniProt
Find proteins for A0AA47NUB9 (Merluccius polli)
Explore A0AA47NUB9
Go to UniProtKB:  A0AA47NUB9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AA47NUB9
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:  0.248 (Depositor), 0.242 (DCC)
  • R-Value Work:  0.232 (Depositor), 0.232 (DCC)
  • R-Value Observed: 0.233 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 69.596α = 90
b = 63.135β = 97.59
c = 104.86γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM067871

Revision History  (Full details and data files)

  • Version 1.0: 2025-06-25
    Type: Initial release
  • Version 1.1: 2025-07-09
    Changes: Database references
