9AZ0 | pdb_00009az0

Crystal crystal of FC2591 peroxidase from Frankia casuarinae


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free:
    0.180 (Depositor), 0.180 (DCC)
  • R-Value Work:
    0.144 (Depositor), 0.144 (DCC)
  • R-Value Observed:
    0.146 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Structural and Biochemical Insights into Lignin-Oxidizing Activity of Bacterial Peroxidases against Soluble Substrates and Kraft Lignin.

Choolaei, Z.Khusnutdinova, A.N.Skarina, T.Stogios, P.Diep, P.Lemak, S.Edwards, E.A.Savchenko, A.Yakunin, A.F.

(2025) ACS Chem Biol 20: 830-844

  • DOI: https://doi.org/10.1021/acschembio.4c00788
  • Primary Citation of Related Structures:
    9AZ0, 9AZ1, 9AZ2

  • PubMed Abstract:

    Great interest has recently been drawn to the production of value-added products from lignin; however, its recalcitrance and high chemical complexity have made this challenging. Dye-decolorizing peroxidases and catalase-peroxidases are among the enzymes that are recognized to play important roles in environmental lignin oxidation. However, bacterial lignin-oxidizing enzymes remain less characterized compared to related proteins from fungi. In this study, screening of 18 purified bacterial peroxidases against the general chromogenic substrate 2,2'-azinobis(3-ethylbenzthiazoline-6-sulfonate) (ABTS) revealed the presence of peroxidase activity in all proteins. Agarose plate-based screens with kraft lignin identified detectable and high lignin oxidation activity in 15 purified proteins. Crystal structures were determined for the DyP-type peroxidases FC2591 from Frankia casuarinae , PF3257 from Pseudomonas fluorescens , and PR9465 from Pseudomonas rhizosphaerae . The structures revealed the presence of hemes with bound oxygens coordinated by conserved His, Arg, and Asp residues as well as three molecular tunnels connecting the heme with the protein surface. Structure-based site-directed mutagenesis of FC2591 identified at least five active site residues as essential for oxidase activity against both ABTS and lignin, whereas the S370A mutant protein showed a three- to 4-fold activity increase with both substrates. HPLC analysis of reaction products of the wild-type FC2591 and S370A mutant proteins with the model lignin dimer guaiacylglycerol-β-guaiacyl ether and kraft lignin revealed the formation of products consistent with the radical coupling of the reaction intermediates. Thus, this study identified novel bacterial heme peroxidases with lignin oxidation activity and provided further insights into our understanding of these enzymes.


  • Organizational Affiliation
    • Department of Chemical Engineering and Applied Chemistry, University of Toronto, Toronto M5S 3E5, Canada.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Dyp-type peroxidase391Frankia casuarinaeMutation(s): 0
Gene Names: Francci3_2591
UniProt
Find proteins for Q2J9T9 (Frankia casuarinae (strain DSM 45818 / CECT 9043 / HFP020203 / CcI3))
Explore Q2J9T9
Go to UniProtKB:  Q2J9T9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2J9T9
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free:  0.180 (Depositor), 0.180 (DCC)
  • R-Value Work:  0.144 (Depositor), 0.144 (DCC)
  • R-Value Observed: 0.146 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 64.434α = 90
b = 71.639β = 109.23
c = 76.638γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHASERphasing
Cootmodel building

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2025-01-15
    Type: Initial release
  • Version 1.1: 2025-07-30
    Changes: Database references
