9A25 | pdb_00009a25

Molecular assembly pathway of the human Nuclear Pore Complex after cell division

Integrative structure models are generated using different types of input information, including varied experimental data, physical principles, statistical preferences, and other prior information.


Integrative Structure Snapshot

  • Multi-Scale: Yes
  • Multi-State: Yes
  • Ordered-State: Yes
  • Deposited Models: 6
  • Representative Model: 6

This is version 1.0 of the entry. See complete history


Literature

A quantitative map of nuclear pore assembly reveals two distinct mechanisms

Otsuka, S.Tempkin, J. O. B.Zhang, W.Politi, A. Z.Rybina, A.Hossain, J. M.Kueblbeck, M.Callegari, A.Koch, B.Sali, A.Ellenberg, J.

(2023) Nature 613: 575-581

  • DOI: https://doi.org/10.1038/s41586-022-05528-w
  • Primary Citation of Related Structures:
    9A25

  • PubMed Abstract:

    Understanding how the nuclear pore complex (NPC) is assembled is of fundamental importance to grasp the mechanisms behind its essential function and understand its role during the evolution of eukaryotes 1-4 . There are at least two NPC assembly pathways-one during the exit from mitosis and one during nuclear growth in interphase-but we currently lack a quantitative map of these events. Here we use fluorescence correlation spectroscopy calibrated live imaging of endogenously fluorescently tagged nucleoporins to map the changes in the composition and stoichiometry of seven major modules of the human NPC during its assembly in single dividing cells. This systematic quantitative map reveals that the two assembly pathways have distinct molecular mechanisms, in which the order of addition of two large structural components, the central ring complex and nuclear filaments are inverted. The dynamic stoichiometry data was integrated to create a spatiotemporal model of the NPC assembly pathway and predict the structures of postmitotic NPC assembly intermediates.


  • Organizational Affiliation
    • Cell Biology and Biophysics Unit, European Molecular Biology Laboratory, Heidelberg, Germany. shotaro.otsuka@univie.ac.at.

Macromolecules
Find similar proteins by:  (by identity cutoff)
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Nup43
380Homo sapiensMutation(s): 0
Gene Names: NUP43
UniProt & NIH Common Fund Data Resources
Find proteins for Q8NFH3 (Homo sapiens)
Explore Q8NFH3
Go to UniProtKB:  Q8NFH3
PHAROS:  Q8NFH3
GTEx:  ENSG00000120253
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8NFH3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Nup160
1,436Homo sapiensMutation(s): 0
Gene Names: NUP160
UniProt & NIH Common Fund Data Resources
Find proteins for Q12769 (Homo sapiens)
Explore Q12769
Go to UniProtKB:  Q12769
PHAROS:  Q12769
GTEx:  ENSG00000030066
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12769
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Nup37
326Homo sapiensMutation(s): 0
Gene Names: NUP37
UniProt & NIH Common Fund Data Resources
Find proteins for Q8NFH4 (Homo sapiens)
Explore Q8NFH4
Go to UniProtKB:  Q8NFH4
PHAROS:  Q8NFH4
GTEx:  ENSG00000075188
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8NFH4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Nup133
1,156Homo sapiensMutation(s): 0
Gene Names: NUP133
UniProt & NIH Common Fund Data Resources
Find proteins for Q8WUM0 (Homo sapiens)
Explore Q8WUM0
Go to UniProtKB:  Q8WUM0
PHAROS:  Q8WUM0
GTEx:  ENSG00000069248
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8WUM0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Nup107
925Homo sapiensMutation(s): 0
Gene Names: NUP107
UniProt & NIH Common Fund Data Resources
Find proteins for P57740 (Homo sapiens)
Explore P57740
Go to UniProtKB:  P57740
PHAROS:  P57740
GTEx:  ENSG00000111581
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP57740
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Nup96
1,817Homo sapiensMutation(s): 0
Gene Names: NUP98
EC: 3.4.21
UniProt & NIH Common Fund Data Resources
Find proteins for P52948 (Homo sapiens)
Explore P52948
Go to UniProtKB:  P52948
PHAROS:  P52948
GTEx:  ENSG00000110713
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP52948
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
SEC13
322Homo sapiensMutation(s): 0
Gene Names: SEC13
UniProt & NIH Common Fund Data Resources
Find proteins for P55735 (Homo sapiens)
Explore P55735
Go to UniProtKB:  P55735
PHAROS:  P55735
GTEx:  ENSG00000157020
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP55735
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
SEH1
360Homo sapiensMutation(s): 0
Gene Names: SEH1L
UniProt & NIH Common Fund Data Resources
Find proteins for Q96EE3 (Homo sapiens)
Explore Q96EE3
Go to UniProtKB:  Q96EE3
PHAROS:  Q96EE3
GTEx:  ENSG00000085415
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ96EE3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Nup85
656Homo sapiensMutation(s): 0
Gene Names: NUP85
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BW27 (Homo sapiens)
Explore Q9BW27
Go to UniProtKB:  Q9BW27
PHAROS:  Q9BW27
GTEx:  ENSG00000125450
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BW27
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Nup155
1,391Homo sapiensMutation(s): 0
Gene Names: NUP155
UniProt & NIH Common Fund Data Resources
Find proteins for O75694 (Homo sapiens)
Explore O75694
Go to UniProtKB:  O75694
PHAROS:  O75694
GTEx:  ENSG00000113569
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO75694
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Nup93
819Homo sapiensMutation(s): 0
Gene Names: NUP93
UniProt & NIH Common Fund Data Resources
Find proteins for Q8N1F7 (Homo sapiens)
Explore Q8N1F7
Go to UniProtKB:  Q8N1F7
PHAROS:  Q8N1F7
GTEx:  ENSG00000102900
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8N1F7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Nup205
2,012Homo sapiensMutation(s): 0
Gene Names: NUP205
UniProt & NIH Common Fund Data Resources
Find proteins for Q92621 (Homo sapiens)
Explore Q92621
Go to UniProtKB:  Q92621
PHAROS:  Q92621
GTEx:  ENSG00000155561
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ92621
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Nup188
1,749Homo sapiensMutation(s): 0
Gene Names: NUP188
UniProt & NIH Common Fund Data Resources
Find proteins for Q5SRE5 (Homo sapiens)
Explore Q5SRE5
Go to UniProtKB:  Q5SRE5
PHAROS:  Q5SRE5
GTEx:  ENSG00000095319
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SRE5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
p54
507Homo sapiensMutation(s): 0
Gene Names: NUP54
UniProt & NIH Common Fund Data Resources
Find proteins for Q7Z3B4 (Homo sapiens)
Explore Q7Z3B4
Go to UniProtKB:  Q7Z3B4
PHAROS:  Q7Z3B4
GTEx:  ENSG00000138750
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7Z3B4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
p58
599Homo sapiensMutation(s): 0
Gene Names: NUP58
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BVL2 (Homo sapiens)
Explore Q9BVL2
Go to UniProtKB:  Q9BVL2
PHAROS:  Q9BVL2
GTEx:  ENSG00000139496
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BVL2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)
Entity ID: 16
MoleculeChains Sequence LengthOrganismDetailsImage
p62
522Homo sapiensMutation(s): 0
Gene Names: NUP62
UniProt & NIH Common Fund Data Resources
Find proteins for P37198 (Homo sapiens)
Explore P37198
Go to UniProtKB:  P37198
PHAROS:  P37198
GTEx:  ENSG00000213024
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP37198
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Integrative Structure Snapshot

  • Multi-Scale: Yes
  • Multi-State: Yes
  • Ordered-State: Yes
  • Deposited Models: 6
  • Representative Model: 6

Structure Validation

View Full Validation Report

View Summary Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2023-01-19
    Type: Initial release
