8WVD | pdb_00008wvd

Crystal structure of Glycosyltransferase in complex with UD1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.66 Å
  • R-Value Free:
    0.233 (Depositor), 0.240 (DCC)
  • R-Value Work:
    0.190 (Depositor), 0.205 (DCC)
  • R-Value Observed:
    0.192 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8WVD

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Enzymatic Synthesis of Novel Terpenoid Glycoside Derivatives Decorated with N -Acetylglucosamine Catalyzed by UGT74AC1.

Li, J.Li, R.Shang, N.Men, Y.Cai, Y.Zeng, Y.Liu, W.Yang, J.Sun, Y.

(2024) J Agric Food Chem 72: 14255-14263

  • DOI: https://doi.org/10.1021/acs.jafc.4c02832
  • Primary Citation Related Structures:
    8WVD

  • PubMed Abstract:

    The addition of the O -linked N -acetylglucosamine ( O -GlcNAc) is a significant modification for active molecules, such as proteins, carbohydrates, and natural products. However, the synthesis of terpenoid glycoside derivatives decorated with GlcNAc remains a challenging task due to the absence of glycosyltransferases, key enzymes for catalyzing the transfer of GlcNAc to terpenoids. In this study, we demonstrated that the enzyme mutant UGT74AC1 T79Y/L48M/R28H/L109I/S15A/M76L/H47R efficiently transferred GlcNAc from uridine diphosphate (UDP)-GlcNAc to a variety of terpenoids. This powerful enzyme was employed to synthesize GlcNAc-decorated derivatives of terpenoids, including mogrol, steviol, andrographolide, protopanaxadiol, glycyrrhetinic acid, ursolic acid, and betulinic acid for the first time. To unravel the mechanism of UDP-GlcNAc recognition, we determined the X-ray crystal structure of the inactivated mutant UGT74AC1 His18A/Asp111A in complex with UDP-GlcNAc at a resolution of 1.66 Å. Through molecular dynamic simulation and activity analysis, we revealed the molecular mechanism and catalytically important amino acids directly involved in the recognition of UDP-GlcNAc. Overall, this study not only provided a potent biocatalyst capable of glycodiversifying natural products but also elucidated the structural basis for UDP-GlcNAc recognition by glycosyltransferases.


  • Organizational Affiliation
    • National Engineering Laboratory for Industrial Enzymes, Tianjin Institute of Industrial Biotechnology, Chinese Academy of Sciences, Tianjin 300308, China.

Macromolecule Content

  • Total Structure Weight: 51.83 kDa
  • Atom Count: 3,945
  • Modeled Residue Count: 450
  • Deposited Residue Count: 454
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Glycosyltransferase454Siraitia grosvenoriiMutation(s): 0
Gene Names: UDPG1
EC: 2.4.1 (PDB Primary Data), 2.4.1.350 (UniProt)
UniProt
Find proteins for K7NBW3 (Siraitia grosvenorii)
Explore K7NBW3
Go to UniProtKB:  K7NBW3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupK7NBW3
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
UD1
(Subject of Investigation/LOI)

Query on UD1



Download:Ideal Coordinates CCD File
B [auth A]URIDINE-DIPHOSPHATE-N-ACETYLGLUCOSAMINE
C17 H27 N3 O17 P2
LFTYTUAZOPRMMI-CFRASDGPSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.66 Å
  • R-Value Free:  0.233 (Depositor), 0.240 (DCC)
  • R-Value Work:  0.190 (Depositor), 0.205 (DCC)
  • R-Value Observed: 0.192 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 49.867α = 90
b = 68.825β = 90
c = 142.689γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
SCALEPACKdata scaling
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China--

Revision History  (Full details and data files)

  • Version 1.0: 2024-09-04
    Type: Initial release
  • Version 1.1: 2024-10-23
    Changes: Structure summary
