8UQH | pdb_00008uqh

X-ray crystal structure of PRMT4 bound to compound YD-1130


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.87 Å
  • R-Value Free:
    0.253 (Depositor), 0.252 (DCC)
  • R-Value Work:
    0.214 (Depositor), 0.214 (DCC)
  • R-Value Observed:
    0.215 (Depositor)

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

An Adenosine Analogue Library Reveals Insights into Active Sites of Protein Arginine Methyltransferases and Enables the Discovery of a Selective PRMT4 Inhibitor.

Deng, Y.Kim, E.J.Song, X.Kulkarni, A.S.Zhu, R.X.Wang, Y.Bush, M.Dong, A.Noinaj, N.Min, J.Xu, W.Huang, R.

(2024) J Med Chem 67: 18053-18069

  • DOI: https://doi.org/10.1021/acs.jmedchem.4c01041
  • Primary Citation of Related Structures:
    8UQH

  • PubMed Abstract:

    Protein arginine methyltransferases (PRMTs) represent promising drug targets. However, the lack of isoform-selective chemical probes poses a significant hurdle in deciphering their biological roles. To address this issue, we devised a library of 100 diverse adenosine analogues, enabling a detailed exploration of the active site of PRMTs. Despite their close homology, our analysis unveiled specific chemical trends unique to the individual members. Notably, compound YD1130 demonstrated over 1000-fold selectivity for PRMT4 (IC 50 < 0.5 nM) over a panel of 38 methyltransferases, including the other PRMTs. Its prodrug YD1342 exhibited potent inhibition on cellular substrate methylation, breast cancer cell colony formation, and tumor growth in the animal model, surpassing or matching known PRMT4-specific inhibitors. In summary, our focused library not only illuminates the intricate active sites of PRMTs to facilitate the discovery of highly potent and isoform-selective probes but also offers a versatile blueprint for identifying chemical probes for other methyltransferases.


  • Organizational Affiliation
    • Department of Medicinal Chemistry and Molecular Pharmacology, Center for Cancer Research, Institute for Drug Discovery, Purdue University, West Lafayette, Indiana 47907, United States.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Histone-arginine methyltransferase CARM1
A, B, C, D
341Homo sapiensMutation(s): 0
Gene Names: CARM1
EC: 2.1.1.319
UniProt & NIH Common Fund Data Resources
Find proteins for Q86X55 (Homo sapiens)
Explore Q86X55
Go to UniProtKB:  Q86X55
PHAROS:  Q86X55
GTEx:  ENSG00000142453
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ86X55
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.87 Å
  • R-Value Free:  0.253 (Depositor), 0.252 (DCC)
  • R-Value Work:  0.214 (Depositor), 0.214 (DCC)
  • R-Value Observed: 0.215 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.726α = 90
b = 98.728β = 90
c = 206.118γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
DIALSdata reduction
DIALSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesCA236356
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesCA281024
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesCA26818

Revision History  (Full details and data files)

  • Version 1.0: 2025-04-02
    Type: Initial release
