8UFW | pdb_00008ufw

CA9 mimic with SLC compound

  • Classification: LYASE
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli
  • Mutation(s): Yes

  • Deposited: 2023-10-04 Released: 2024-12-18
  • Deposition Author(s): Peat, T.S.
  • Funding Organization(s): Not funded

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.22 Å
  • R-Value Free:
    0.143 (Depositor), 0.142 (DCC)
  • R-Value Work:
    0.113 (Depositor), 0.112 (DCC)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

An ureido-substituted benzenesulfonamide carbonic anhydrase inhibitor exerts a potent antitumor effect in vitro and in vivo.

Gazzaroli, G.Tavani, C.Filiberti, S.Massardi, M.L.Turati, M.Garattini, G.Peat, T.S.Pieraccini, G.Angeli, A.Supuran, C.T.Carta, F.Giacomini, A.Ronca, R.

(2025) Exp Hematol Oncol 14: 104-104

  • DOI: https://doi.org/10.1186/s40164-025-00690-z
  • Primary Citation of Related Structures:
    8UFW

  • PubMed Abstract:

    Carbonic anhydrase IX (CA IX) is a tumor-specific metallo-enzyme upregulated during hypoxic conditions and implicated in several pathophysiological processes where tissue pH regulation is required such as cancer, cell invasion, metastatic and stem-like features, drug resistance and recurrence. Indeed, CA IX expression has been correlated with poor prognosis, aggressiveness and disease progression in several solid tumors, and its targeting has been proposed as a therapeutic approach to treat aggressive cancers. To date, several CA IX targeting approaches have been developed to inhibit its activity in neoplastic tissues including the clinical grade (Phase Ib/II) ureido-substituted benzenesulfonamide SLC-0111, which has been widely investigated over the past years. In this study, we carried out a detailed characterization of a SLC-0111 derivative, FC-531, evaluating its anti-tumor potential in parallel with SLC-0111 on a panel of human cell lines representative of different cancer types. Finally, we evaluated the safety profile of FC-531 in vivo and demonstrated its capacity to reduce tumor growth and metastatization in vivo. Together, our data provide the rationale for the exploitation of FC-531 as a potent CA IX inhibitor for the management of different CA IX- expressing solid tumors.


  • Organizational Affiliation
    • Department of Molecular and Translational Medicine, University of Brescia, Brescia, 25123, Italy.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Carbonic anhydrase 2260Homo sapiensMutation(s): 10
Gene Names: CA2
EC: 4.2.1.1 (PDB Primary Data), 4.2.1.69 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P00918 (Homo sapiens)
Explore P00918
Go to UniProtKB:  P00918
PHAROS:  P00918
GTEx:  ENSG00000104267
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00918
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
WJN (Subject of Investigation/LOI)
Query on WJN

Download Ideal Coordinates CCD File
C [auth A]4-{[4-(trifluoromethyl)phenyl]carbamamido}benzene-1-sulfonamide
C14 H12 F3 N3 O3 S
PTTQRLLAHZHAEV-UHFFFAOYSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
E [auth A],
F [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
DMS
Query on DMS

Download Ideal Coordinates CCD File
D [auth A]DIMETHYL SULFOXIDE
C2 H6 O S
IAZDPXIOMUYVGZ-UHFFFAOYSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
B [auth A]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
G [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.22 Å
  • R-Value Free:  0.143 (Depositor), 0.142 (DCC)
  • R-Value Work:  0.113 (Depositor), 0.112 (DCC)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 41.985α = 90
b = 41.414β = 103.968
c = 72.309γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data

  • Released Date: 2024-12-18
  • Deposition Author(s): Peat, T.S.

Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2024-12-18
    Type: Initial release
  • Version 1.1: 2025-09-17
    Changes: Database references
