8Q3B

The closed state of the ASFV apo-RNA polymerase


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.69 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structure of the recombinant RNA polymerase from African Swine Fever Virus.

Pilotto, S.Sykora, M.Cackett, G.Dulson, C.Werner, F.

(2024) Nat Commun 15: 1606-1606

  • DOI: https://doi.org/10.1038/s41467-024-45842-7
  • Primary Citation of Related Structures:
    8Q3B, 8Q3K

  • PubMed Abstract:

    African Swine Fever Virus is a Nucleo-Cytoplasmic Large DNA Virus that causes an incurable haemorrhagic fever in pigs with a high impact on global food security. ASFV replicates in the cytoplasm of the infected cell and encodes its own transcription machinery that is independent of cellular factors, however, not much is known about how this system works at a molecular level. Here, we present methods to produce recombinant ASFV RNA polymerase, functional assays to screen for inhibitors, and high-resolution cryo-electron microscopy structures of the ASFV RNAP in different conformational states. The ASFV RNAP bears a striking resemblance to RNAPII with bona fide homologues of nine of its twelve subunits. Key differences include the fusion of the ASFV assembly platform subunits RPB3 and RPB11, and an unusual C-terminal domain of the stalk subunit vRPB7 that is related to the eukaryotic mRNA cap 2´-O-methyltransferase 1. Despite the high degree of structural conservation with cellular RNA polymerases, the ASFV RNAP is resistant to the inhibitors rifampicin and alpha-amanitin. The cryo-EM structures and fully recombinant RNAP system together provide an important tool for the design, development, and screening of antiviral drugs in a low biosafety containment environment.


  • Organizational Affiliation

    Institute for Structural and Molecular Biology, Division of Biosciences, University College London, Gower Street, London, WC1E 6BT, United Kingdom.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase RPB1 homolog1,450African swine fever virus BA71VMutation(s): 0
Gene Names: Ba71V-99NP1450L
EC: 2.7.7.6
UniProt
Find proteins for P42486 (African swine fever virus (strain Badajoz 1971 Vero-adapted))
Explore P42486
Go to UniProtKB:  P42486
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP42486
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase RPB2 homolog1,243African swine fever virus BA71VMutation(s): 0
Gene Names: Ba71V-053
UniProt
Find proteins for P42487 (African swine fever virus (strain Badajoz 1971 Vero-adapted))
Explore P42487
Go to UniProtKB:  P42487
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP42487
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase RPB3-11 homolog359African swine fever virus BA71VMutation(s): 0
Gene Names: Ba71V-113
UniProt
Find proteins for Q65184 (African swine fever virus (strain Badajoz 1971 Vero-adapted))
Explore Q65184
Go to UniProtKB:  Q65184
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ65184
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase RPB7 homolog339African swine fever virus BA71VMutation(s): 0
Gene Names: Ba71V-105
UniProt
Find proteins for Q89907 (African swine fever virus (strain Badajoz 1971 Vero-adapted))
Explore Q89907
Go to UniProtKB:  Q89907
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ89907
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase RPB5 homolog205African swine fever virus BA71VMutation(s): 0
Gene Names: Ba71V-108
UniProt
Find proteins for Q65181 (African swine fever virus (strain Badajoz 1971 Vero-adapted))
Explore Q65181
Go to UniProtKB:  Q65181
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ65181
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase RPB6 homolog147African swine fever virus BA71VMutation(s): 0
Gene Names: Ba71V-069
UniProt
Find proteins for P42484 (African swine fever virus (strain Badajoz 1971 Vero-adapted))
Explore P42484
Go to UniProtKB:  P42484
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP42484
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Uncharacterized protein C122RG [auth I]105African swine fever virus BA71VMutation(s): 0
Gene Names: Ba71V-065
UniProt
Find proteins for Q65157 (African swine fever virus (strain Badajoz 1971 Vero-adapted))
Explore Q65157
Go to UniProtKB:  Q65157
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ65157
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase RPB10 homologH [auth J]80African swine fever virus BA71VMutation(s): 0
Gene Names: Ba71V-95
UniProt
Find proteins for P42488 (African swine fever virus (strain Badajoz 1971 Vero-adapted))
Explore P42488
Go to UniProtKB:  P42488
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP42488
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.69 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC4
MODEL REFINEMENTPHENIX1.20
MODEL REFINEMENTCoot0.9.8.7

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/X017028/1
Wellcome TrustUnited KingdomWT207446/Z/17/Z
Wellcome TrustUnited KingdomWT108877/B/15/Z

Revision History  (Full details and data files)

  • Version 1.0: 2024-02-14
    Type: Initial release
  • Version 1.1: 2024-03-06
    Changes: Database references
