Arf Family GTPases are present in Asgard archaea
Menetrey, J.To be published.
Experimental Data Snapshot
Starting Model: in silico
View more details
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
GTP-binding protein | 189 | Promethearchaeati archaeon | Mutation(s): 0  Gene Names: FK733_07565 | ||
UniProt | |||||
Find proteins for A0A8J7ZFD1 (Asgard group archaeon) Explore A0A8J7ZFD1  Go to UniProtKB:  A0A8J7ZFD1 | |||||
Entity Groups   | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | A0A8J7ZFD1 | ||||
Sequence AnnotationsExpand | |||||
|
Ligands 2 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
GDP (Subject of Investigation/LOI) Query on GDP | C [auth A], E [auth B] | GUANOSINE-5'-DIPHOSPHATE C10 H15 N5 O11 P2 QGWNDRXFNXRZMB-UUOKFMHZSA-N | |||
MG (Subject of Investigation/LOI) Query on MG | D [auth A], F [auth B] | MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N |
Length ( Å ) | Angle ( ˚ ) |
---|---|
a = 43.29 | α = 90 |
b = 59.93 | β = 102.09 |
c = 72.35 | γ = 90 |
Software Name | Purpose |
---|---|
BUSTER | refinement |
ARP/wARP | model building |
autoPROC | data reduction |
autoPROC | data scaling |
PHASER | phasing |
Funding Organization | Location | Grant Number |
---|---|---|
Agence Nationale de la Recherche (ANR) | France | ANR-20-CE13-0007 |
