8K8M | pdb_00008k8m

Crystallographic structure of Lysozyme C from chicken

PDB DOI: https://doi.org/10.2210/pdb8K8M/pdb

Classification: ANTIMICROBIAL PROTEIN
Organism(s): Gallus gallus
Mutation(s): No

Deposited: 2023-07-31 Released: 2024-08-07
Deposition Author(s): Zheng, P., Shang, G., Jin, J., He, L.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.188 (Depositor), 0.180 (DCC)
R-Value Work:
0.159 (Depositor), 0.170 (DCC)
R-Value Observed:
0.161 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

AI-Guided Droplet Microreactors Enable Rapid and Reproducible Protein Crystallization

Shang, G., Zheng, P., Ni, H., Wei, S., Li, L., Lei, X., Wu, Z., He, X., Wang, Z., Zhu, Z., Ou, H., He, L., Li, Z., Jin, T., Zhao, G.

(2026) Small

DOI: https://doi.org/10.1002/smll.202510977

Macromolecule Content

Total Structure Weight: 14.52 kDa
Atom Count: 1,185
Modeled Residue Count: 129
Deposited Residue Count: 129
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lysozyme C	A	129	Gallus gallus	Mutation(s): 0 EC: 3.2.1.17
UniProt
Find proteins for P00698 (Gallus gallus) Explore P00698 Go to UniProtKB: P00698
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P00698
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.188 (Depositor), 0.180 (DCC)
R-Value Work: 0.159 (Depositor), 0.170 (DCC)
R-Value Observed: 0.161 (Depositor)

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 78.537	α = 90
b = 78.537	β = 90
c = 37.56	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
CrysalisPro	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2024-08-07

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2024-08-07
Type: Initial release
Version 1.1: 2024-10-30
Changes: Structure summary
Version 1.2: 2026-02-18
Changes: Database references
