8J9V

Cryo-EM structure of the African swine fever virus topoisomerase 2 complexed with Cut02aDNA and etoposide (EDI-1)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.71 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

A unified view on enzyme catalysis by cryo-EM study of a DNA topoisomerase.

Chang, C.M.Wang, S.C.Wang, C.H.Pang, A.H.Yang, C.H.Chang, Y.K.Wu, W.J.Tsai, M.D.

(2024) Commun Chem 7: 45-45

  • DOI: https://doi.org/10.1038/s42004-024-01129-y
  • Primary Citation of Related Structures:
    8J87, 8J88, 8J89, 8J8A, 8J8B, 8J8C, 8J9V, 8J9W, 8J9X, 8JA1, 8JA2

  • PubMed Abstract:

    The theories for substrate recognition in enzyme catalysis have evolved from lock-key to induced fit, then conformational selection, and conformational selection followed by induced fit. However, the prevalence and consensus of these theories require further examination. Here we use cryogenic electron microscopy and African swine fever virus type 2 topoisomerase (AsfvTop2) to demonstrate substrate binding theories in a joint and ordered manner: catalytic selection by the enzyme, conformational selection by the substrates, then induced fit. The apo-AsfvTop2 pre-exists in six conformers that comply with the two-gate mechanism directing DNA passage and release in the Top2 catalytic cycle. The structures of AsfvTop2-DNA-inhibitor complexes show that substantial induced-fit changes occur locally from the closed apo-conformer that however is too far-fetched for the open apo-conformer. Furthermore, the ATPase domain of AsfvTop2 in the MgAMP-PNP-bound crystal structures coexist in reduced and oxidized forms involving a disulfide bond, which can regulate the AsfvTop2 function.


  • Organizational Affiliation

    Institute of Biological Chemistry, Academia Sinica, Taipei, 115, Taiwan.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA topoisomerase 2
A, B
1,197African swine fever virusMutation(s): 0
Gene Names: P1192R
UniProt
Find proteins for A0A0A1E3Q0 (African swine fever virus)
Explore A0A0A1E3Q0
Go to UniProtKB:  A0A0A1E3Q0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0A1E3Q0
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*AP*GP*GP*TP*AP*TP*GP*TP*AP*GP*GP*C)-3')C,
D [auth E]
13Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*GP*CP*CP*GP*CP*CP*TP*AP*CP*AP*TP*AP*CP*CP*TP*C)-3')E [auth D],
F
17Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
EVP (Subject of Investigation/LOI)
Query on EVP

Download Ideal Coordinates CCD File
I [auth D],
J [auth F]
(5S,5aR,8aR,9R)-9-(4-hydroxy-3,5-dimethoxyphenyl)-8-oxo-5,5a,6,8,8a,9-hexahydrofuro[3',4':6,7]naphtho[2,3-d][1,3]dioxol -5-yl 4,6-O-[(1R)-ethylidene]-beta-D-glucopyranoside
C29 H32 O13
VJJPUSNTGOMMGY-MRVIYFEKSA-N
MG (Subject of Investigation/LOI)
Query on MG

Download Ideal Coordinates CCD File
G [auth A],
H [auth B]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.71 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Academia Sinica (Taiwan)TaiwanAS-KPQ-109-TPP2

Revision History  (Full details and data files)

  • Version 1.0: 2024-02-07
    Type: Initial release
  • Version 1.1: 2024-04-17
    Changes: Database references
